ESC4000 DHD G4
Model ESC4000 DHD G4Part no. 90SF00Y2-M00040EAN 4718017424813
34 specifications
- ColourSilver
- Built-in processorYes
- Number of DIMM slots16
- Number of storage drives supported4
- On-board graphics card modelAspeed AST2500
- Chassis typeRack (1U)
Overview
- Colour
- Silver
- Built-in processor
- Yes
- Number of DIMM slots
- 16
- Number of storage drives supported
- 4
- On-board graphics card model
- Aspeed AST2500
- Chassis type
- Rack (1U)
- Brand
- ASUS
- Category
- Server Barebone
- Model
- ESC4000 DHD G4
- Part number
- 90SF00Y2-M00040
- EAN / UPC
- 4718017424813
- Also known as
- ASUS ESC4000 DHD G4 Intel® C621 LGA 3647 (Socket P) Rack (1U) Silver
Specifications
34 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Motherboard chipset | Intel® C621 |
| Processor socket | LGA 3647 (Socket P) |
| Number of processors supported | 2 |
Memory
| Specification | Value |
|---|---|
| Number of DIMM slots | 16 |
| Supported memory types | DDR4-SDRAM |
| Supported DIMM module capacities | 32GB, 64GB, 128GB |
| Maximum RDIMM memory | 2 TB |
| Supported RDIMM clock speeds | 2666,2933 MHz |
Storage
| Specification | Value |
|---|---|
| Number of storage drives supported | 4 |
| Hot-swap HDD bays | No |
| Number of 2.5" bays | 4 |
| Supported storage drive interfaces | Serial ATA |
| RAID levels | 0, 1, 5, 10 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card model | Aspeed AST2500 |
| Maximum graphics card memory | 64 MB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| LAN controller | Intel® X550 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 3 |
| VGA (D-Sub) ports quantity | 1 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84714100 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (1U) |
| Product colour | Silver |
Power
| Specification | Value |
|---|---|
| Power supply | 2200 W |
| Redundant power supply (RPS) support | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 439.5 mm |
| Height | 43.6 mm |
| Width | 998 mm |
Other features
| Specification | Value |
|---|---|
| Memory slots | 16 (6-channel per CPU, 8 DIMM per CPU) |
| On-board graphics card | Yes |
