VIGI C400HP
Model VIGI C400HPPart no. VIGI C400HP-2.8EAN 6935364072322
47 specifications
- ConnectivityWired
- TypeIP security camera
- Weight195 g
- ColourWhite
- Form factorDome
- Camera pan controlYes
Overview
- Connectivity
- Wired
- Type
- IP security camera
- Weight
- 195 g
- Colour
- White
- Form factor
- Dome
- Camera pan control
- Yes
- Brand
- TP-Link
- Category
- Security Camera
- Model
- VIGI C400HP
- Part numbers
- VIGI C400HP-2.8, VIGI C400HP-4
- EAN / UPC
- 6935364072322, 840030701436, 6935364072292, 6935364072308 +1 more
- Also known as
- TP-Link VIGI 3MP Turret Network Camera
Specifications
47 specifications in 15 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| PTZ control | Yes |
Design
| Specification | Value |
|---|---|
| Form factor | Dome |
| Mounting type | Ceiling |
| Product colour | White |
| Housing material | Plastic |
| International Protection (IP) code | IP67 |
Camera
| Specification | Value |
|---|---|
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Minimum illumination | 0.1 lx |
| Angle of rotation | 360° |
| Lens viewing angle, horizontal | 92° |
| Lens viewing angle, vertical | 48° |
| Lens viewing angle, diagonal | 114° |
| Tilt angle range | 0 - 85° |
| Pan range | 0 - 360° |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Number of sensors | 1 |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 1 |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 30 m |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 2304 x 1296 pixels |
| Total megapixels | 3 MP |
| Video compression formats | H.264, H.265 |
| Frame rate | 30 fps |
| Bit rate | 64 Kbps - 6 Mbps |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Security
| Specification | Value |
|---|---|
| Password protection | Yes |
| HTTPS encryption | Yes |
| IP address filtering | Yes |
| Mirror | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| DC output voltage | 12 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 123 mm |
| Depth | 83 mm |
| Height | 123 mm |
| Weight | 195 g |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85258900 |
