TP-Link Tapo TC46 security camera Spherical IP security camera Indoor & outdoor
TP-Link

Tapo TC46 security camera Spherical IP security camera Indoor & outdoor

3840 x 2160 pixels Ceiling/Wall/Pole

Model TC46EAN 1210002608848

88 specifications
  • ConnectivityWired & Wireless
  • TypeIP security camera
  • ColourBlack, White
  • Form factorSpherical
  • Camera pan controlYes
  • Sensor typeCMOS
See all specifications

Overview

Connectivity
Wired & Wireless
Type
IP security camera
Colour
Black, White
Form factor
Spherical
Camera pan control
Yes
Sensor type
CMOS
Brand
TP-Link
Model
TC46
Part number
TC46
EAN / UPC
1210002608848
Also known as
TP-Link Tapo TC46 security camera Spherical IP security camera Indoor & outdoor 3840 x 2160 pixels Ceiling/Wall/Pole

Specifications

88 specifications in 18 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired & Wireless
Virtual assistantAmazon Alexa & Google Assistant
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Infrared (IR) cut-off filterYes
Built-in lightYes

Design

Form factorSpherical
Mounting typeCeiling/Wall/Pole
Product colourBlack, White
LED indicatorsYes
Protection featuresDust resistant, Heat resistant, Rain proof, Snow resistant, Weather resistant
International Protection (IP) codeIP66
WeatherproofYes

Camera

Camera pan controlYes
Camera tilt controlYes
Field of view (FOV) angle105°
Lens viewing angle, horizontal88°
Lens viewing angle, vertical45°
Lens viewing angle, diagonal105°
Tilt angle range0 - 53°
Pan range0 - 326°

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 27 mm (1 / 27")
Progressive scanYes

Lens system

Number of lenses1
Zoom capabilityYes
Digital zoom18x
Maximum aperture number1.6
Fixed focal length4 mm

Night vision

Night visionYes
LED typeIR
Infra-red wavelength850 nm

Video

Maximum resolution3840 x 2160 pixels
Total megapixels8 MP
Video formats supportedH.264
Supported graphics resolutions2880 x 1620
Supported video modes1620p
Frame rate25 fps
Noise reductionYes
Image quality adjustmentDNR

Audio

Built-in speaker(s)Yes
Built-in microphoneYes

Network

Ethernet LANYes
Wi-FiYes
Networking standardsIEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Supported network protocolsTCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Channel bandwidth2400 MHz
Live viewYes
Works with Amazon AlexaYes
Works with the Google AssistantYes

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size512 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports1

Security

Built-in sirenYes
Siren noise level99 dB
Active tampering alarmYes
Alert notification typePush notification, Snapshot alert message
Intelligent Video Surveillance (IVS) system featuresHuman detection, Line crossing detection, Moving object, Pet detection, Vehicle detection
Security algorithms128-bit AES, SSL/TLS, WPA, WPA2-PSK, WPA3
Video motion detectionYes

Management features

Cloud-managedYes
Reset buttonYes

Power

Power source typeAC, DC
AC input voltage100-240 V
AC input frequency50/60 Hz
Power consumption (typical)3.9 W
Power consumption (max)7.41 W
DC output voltage9
DC output current0.85 A

Operational conditions

Operating temperature (T-T)-30 - 60 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)0 - 90%

Weight & dimensions

Width147.4 mm
Depth74.7 mm
Height165.4 mm

Packaging data

Package typeBox

Packaging content

Number of cameras1
Mounting kitYes
Mounting brackets includedYes
Screws includedYes
ManualYes
Packaging contentTC43 Camera Power Adapter Mounting Anchors Mounting Screws Bracket Screws Mounting Template Mounting Bracket Waterproof Seal Waterproof Cable Attachments Quick Start Guide
