Tapo C420S1
Model Tapo C420S1Part no. TAPO C420S1EAN 840030705106
53 specifications
- ConnectivityWireless
- TypeCCTV security camera
- LED indicatorsYes
- Sensor typeVGA
- Number of lenses2
- Maximum resolution2560 x 1440 pixels
Overview
- Connectivity
- Wireless
- Type
- CCTV security camera
- LED indicators
- Yes
- Sensor type
- VGA
- Number of lenses
- 2
- Maximum resolution
- 2560 x 1440 pixels
- Brand
- TP-Link
- Category
- Security Camera
- Model
- Tapo C420S1
- Part number
- TAPO C420S1
- EAN / UPC
- 840030705106, 4897098685105, 4897098685112
- Also known as
- TP-Link Tapo Smart Wire-Free Security Camera System, 1-Camera System
Specifications
53 specifications in 15 groups
Performance
| Specification | Value |
|---|---|
| Type | CCTV security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wireless |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Built-in light | Yes |
Design
| Specification | Value |
|---|---|
| LED indicators | Yes |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | VGA |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 2 |
| Fixed focal length | 3.18 mm |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 15 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 2560 x 1440 pixels |
| Video compression formats | H.264 |
| Supported graphics resolutions | 2560 x 1440 |
| Frame rate | 20 fps |
| Video streaming | Yes |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Audio system | 2-way |
| Built-in microphone | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | Yes |
| Bluetooth | No |
| Supported network protocols | TCP/IP, ICMP, DNS, HTTPS, TCP, UDP |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Channel bandwidth | 2400 MHz |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | Yes |
Security
| Specification | Value |
|---|---|
| Built-in siren | Yes |
| Motion sensor | Yes |
| Video motion detection | Yes |
Management features
| Specification | Value |
|---|---|
| Reset button | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 45 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 110.6 mm |
| Depth | 64.2 mm |
| Height | 64.2 mm |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
| Cables included | LAN (RJ-45), USB |
| Mounting brackets included | Yes |
| Screws included | Yes |
| Drilling template included | Yes |
| Battery included | Yes |
| Manual | Yes |
| Mounting template | Yes |
| Packaging content | Tapo C420 Cameras (Battery Included) Tapo H200 Hub USB Adapter USB Adapter Cable DC Power Adapter Mounting Screws Mounting Templates Camera Brackets Quick Start Guide RJ45 Ethernet Cable |
