TP-Link NC230 security camera Cube IP security camera Indoor

1280 x 720 pixels Desk

Model NC230EAN 6935364094638

65 specifications

ConnectivityWired & Wireless
TypeIP security camera
ColourWhite
Form factorCube
Field of view (FOV) angle64°
Sensor typeCMOS

See all specifications

Overview

Connectivity: Wired & Wireless
Type: IP security camera
Colour: White
Form factor: Cube
Field of view (FOV) angle: 64°
Sensor type: CMOS

Brand: TP-Link
Category: Security Camera
Model: NC230
Part number: NC230
EAN / UPC: 6935364094638, 6935640946385
Also known as: TP-Link NC230 security camera Cube IP security camera Indoor 1280 x 720 pixels Desk

Specifications

65 specifications in 20 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Day/night mode	Yes
Certification	FCC, CE

Design

Specification	Value
Form factor	Cube
Mounting type	Desk
Product colour	White

Camera

Specification	Value
Field of view (FOV) angle	64°

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 2 mm (1 / 2")
Progressive scan	Yes

Lens system

Specification	Value
Zoom capability	Yes
Digital zoom	4x
Fixed focal length	3.85 mm
Focus adjustment	2.8

Night vision

Specification	Value
Night vision	Yes

Video

Specification	Value
Maximum resolution	1280 x 720 pixels
Total megapixels	1 MP
Video formats supported	H.264
Supported graphics resolutions	1280 x 720 (HD 720)
Supported video modes	720p
Frame rate	20 fps
Flip & mirror	Yes
Image quality adjustment	Brightness, Contrast, Saturation

Audio

Specification	Value
Built-in microphone	Yes
Audio detection	Yes

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	Yes
Ethernet interface type	Fast Ethernet
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Supported network protocols	Bonjour, TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP,DNS, UPnP, HTTP and UDP
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	150 Mbit/s
Cabling technology	10/100Base-T(X)
Frequency band	2.4 - 2.4835 GHz

Storage

Specification	Value
Built-in HDD	No

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
Microphone in	Yes
DC-in jack	Yes
Interface	RJ-45

Security

Specification	Value
Alert notification type	E-mail
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Video motion detection	Yes

Management features

Specification	Value
Reset button	Yes

Power

Specification	Value
Power consumption (max)	5.4 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%

System requirements

Specification	Value
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Mobile operating systems supported	Android 3.0, Android 3.1, Android 3.2, Android 4.0, Android 4.1, Android 4.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, iOS 7.0, iOS 7.1, iOS 7.2, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3

Weight & dimensions

Specification	Value
Width	137 mm
Depth	69 mm
Height	137 mm

Sustainability

Specification	Value
Compliance certificates	RoHS

Packaging data

Specification	Value
Package width	79.5 mm
Package depth	223 mm
Package height	128 mm

Packaging content

Specification	Value
Number of cameras	1
Cables included	LAN (RJ-45)
Manual	Yes
AC adapter included	Yes
Quick installation guide	Yes
