TP-Link InSight S385DPS
TP-Link

InSight S385DPS

Model InSight S385DPSPart no. INSIGHT S385DPSEAN 810142823791

96 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight1.12 kg
  • ColourWhite
  • Form factorBullet
  • Minimum illumination0 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
1.12 kg
Colour
White
Form factor
Bullet
Minimum illumination
0 lx
Brand
TP-Link
Model
InSight S385DPS
Part number
INSIGHT S385DPS
EAN / UPC
810142823791, 8885020627824
Also known as
TP-Link InSight S385DPS Bullet IP security camera Outdoor 5456 x 1520 pixels Wall

Specifications

96 specifications in 18 groups

Performance

TypeIP security camera
Placement supportedOutdoor
Connectivity technologyWired
Maximum operating distance76 m
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Infrared (IR) cut-off filterYes
Remote viewingYes
Dynamic range120 dB

Design

Form factorBullet
Mounting typeWall
Product colourWhite
Housing materialMetal
Protection featuresWaterproof
International Protection (IP) codeIP67
IK codeIK10
WeatherproofYes

Camera

Minimum illumination0 lx
Lens viewing angle, horizontal180°
Lens viewing angle, vertical51°
Lens viewing angle, diagonal180°
Tilt angle range0 - 90°
Camera shutter speed1/3 to 1/10000

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 1.79 mm (1 / 1.79")
Progressive scanYes

Panoramic camera

Sensor type (panoramic camera)CMOS

Lens system

Detect distance76 m
Observe distance29 m
Recognize distance14 m
Fixed focusYes
Fixed focal length5 mm

Night vision

Night visionYes
LED typeIR/White

Video

Maximum resolution5456 x 1520 pixels
Total megapixels8 MP
Video compression formatsH.264, H.264+, H.265, H.265+
Video recordingYes
Back Light Compensation (BLC)Yes
Bit rateMain Stream: 256 Kbps to 8 Mbps, Sub-Stream: 64 Kbps to 1024 Kbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Digital Wide Dynamic Range (DWDR)Yes
Highlight Compensation (HLC)Yes
Image quality adjustmentBrightness, Contrast, Mirror, Saturation, Sharpness

Audio

Built-in speaker(s)Yes
Audio system2-way
Audio input channels1.0 channels
Audio output channels1.0 channels
Audio formats supportedG.711 A-law
Sample rate8 kHz
Built-in microphoneYes
Number of microphones1
Bit rate range0 - 64 Kbit/s

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Networking standardsIEEE 802.3at
Supported network protocolsTCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
SIM card slotYes
SIM card typeMicroSIM
Live viewYes

Storage

Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size512 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
DC-in jackYes

Security

Built-in sirenYes
Password protectionYes
Alert notification typePush notification
Digest authenticationYes
HTTPS encryptionYes
Human and vehicle targets classificationYes
IP address filteringYes
MirrorYes
Motion sensorYes
Video motion detectionYes

Management features

Web-based managementYes
Web browserYes
Cloud-managedYes
Reset buttonYes

Power

Power source typeDC, PoE
Power consumption (max)18 W
Power consumption (Power over Ethernet (PoE))21 W
DC output voltage12

Operational conditions

Operating temperature (T-T)-30 - 60 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%

Weight & dimensions

Width116 mm
Height90 mm
Length266 mm
Weight1.12 kg

Packaging content

Number of cameras1
Mounting kitYes
Screws includedYes
Drilling template includedYes
ManualYes
