TP-Link INSIGHT S225 2.8MM
TP-Link

INSIGHT S225 2.8MM

Model INSIGHT S225 2.8MMEAN 1210002606646

89 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight500 g
  • ColourWhite
  • Form factorBullet
  • Minimum illumination0 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
500 g
Colour
White
Form factor
Bullet
Minimum illumination
0 lx
Brand
TP-Link
Model
INSIGHT S225 2.8MM
Part number
INSIGHT S225 2.8MM
EAN / UPC
1210002606646
Also known as
TP-Link INSIGHT S225 2.8MM security camera Bullet IP security camera Outdoor 1920 x 1080 pixels Ceiling

Specifications

89 specifications in 17 groups

Performance

TypeIP security camera
Placement supportedOutdoor
Connectivity technologyWired
Maximum operating distance47 m
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Infrared (IR) cut-off filterYes
Remote viewingYes
Dynamic range52 dB

Design

Form factorBullet
Mounting typeCeiling
Product colourWhite
Housing materialMetal
Protection featuresWaterproof
International Protection (IP) codeIP67
IK codeIK10
WeatherproofYes

Camera

Minimum illumination0 lx
Lens viewing angle, horizontal98.8°
Lens viewing angle, vertical53.5°
Lens viewing angle, diagonal117°
Tilt angle range0 - 75°
Camera shutter speed1/3 to 1/10000

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 3 mm (1 / 3")
Progressive scanYes

Lens system

Detect distance47 m
Observe distance19 m
Recognize distance9 m
Fixed focusYes
Identify distance5 m
Maximum aperture number2
Fixed focal length2.8 mm

Night vision

Night visionYes
LED typeIR/White

Video

Maximum resolution1920 x 1080 pixels
Total megapixels2 MP
Video compression formatsH.264, H.264+, H.265, H.265+
Supported graphics resolutions1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
Video recordingYes
Back Light Compensation (BLC)Yes
Bit rateMain Stream: 256 Kbps to 4 Mbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Digital Wide Dynamic Range (DWDR)Yes
Highlight Compensation (HLC)Yes
Image quality adjustmentBrightness, Contrast, Mirror, Saturation, Sharpness

Audio

Built-in speaker(s)Yes
Audio input channels1.0 channels
Audio formats supportedG.711 A-law
Sample rate8 kHz
Built-in microphoneYes
Number of microphones1
Bit rate range0 - 64 Kbit/s

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Networking standardsIEEE 802.3af, IEEE 802.3at
Supported network protocolsTCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Live viewYes

Ports & interfaces

DC-in jackYes

Security

Built-in sirenYes
Password protectionYes
Alert notification typePush notification
HTTPS encryptionYes
Human and vehicle targets classificationYes
IP address filteringYes
MirrorYes
Motion sensorYes
Video motion detectionYes

Management features

Web browserYes
Cloud-managedYes
Reset buttonYes

Power

Power source typeDC, PoE
Power consumption (max)6.3 W
Power consumption (Power over Ethernet (PoE))6.7 W
DC output voltage12

Operational conditions

Operating temperature (T-T)-30 - 60 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%

Weight & dimensions

Height85.7 mm
Diameter11.3 cm
Weight500 g

Packaging data

Package typeBox

Packaging content

Number of cameras1
Mounting kitYes
Screws includedYes
Drilling template includedYes
ManualYes
