TP-Link C540-W V1
TP-Link

C540-W V1

Model C540-W V1Part no. VIGI C540-W(4MM)EAN 840030703799

82 specifications
  • ConnectivityWired & Wireless
  • TypeIP security camera
  • ColourBlack, White
  • Form factorTurret
  • Camera pan controlYes
  • Sensor typeCMOS
See all specifications

Overview

Connectivity
Wired & Wireless
Type
IP security camera
Colour
Black, White
Form factor
Turret
Camera pan control
Yes
Sensor type
CMOS
Brand
TP-Link
Model
C540-W V1
Part number
VIGI C540-W(4MM)
EAN / UPC
840030703799, 4897098683798
Also known as
TP-Link VIGI 4MP Outdoor Full-Color Wi-Fi Pan Tilt Network Camera

Specifications

82 specifications in 20 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired & Wireless
CertificationRCM, BSMI, VCCI, NCC, JRF, KC

Design

Form factorTurret
Mounting typeCeiling/wall
Product colourBlack, White
Housing materialPlastic
International Protection (IP) codeIP66

Camera

Camera pan controlYes
Camera tilt controlYes
Lens viewing angle, horizontal79°
Lens viewing angle, vertical43°
Lens viewing angle, diagonal93°
Tilt angle range0 - 120°
Tilt speed44 °/sec
Pan range0 - 350°
Pan speed44 °/sec

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 3 mm (1 / 3")
Progressive scanYes

Lens system

Number of lenses1
Zoom capabilityYes
Detect distance80 m
Observe distance33 m
Recognize distance16 m
Lens diameter4 mm
Identify distance8 m

Night vision

Night visionYes
Night vision distance30 m
LED typeIR
Infra-red wavelength850 nm

Video

Maximum resolution2560 x 1440 pixels
Total megapixels4 MP
Video compression formatsH.264, H.264+, H.265, H.265+
Supported graphics resolutions320 x 240, 352 x 288, 640 x 480 (VGA), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440
Frame rate30 fps
Video streamingYes
Noise reductionYes
Noise reduction technology3D noise reduction
Bit rate256 Kbps - 4 Mbps
Digital Wide Dynamic Range (DWDR)Yes
Image quality adjustmentBrightness, Contrast, Mirror, Saturation, Sharpness
Privacy maskingYes

Audio

Built-in speaker(s)Yes
Built-in microphoneYes

Network

Ethernet LANYes
Wi-FiYes
BluetoothNo
Ethernet interface typeFast Ethernet
Supported network protocolsTCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Live viewYes
Number of simultaneous live view channels3 channels

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports1

Security

Password protectionYes
Digest authenticationYes
HTTPS encryptionYes
IP address filteringYes
Intelligent Video Surveillance (IVS) system featuresHuman detection
MirrorYes
Security algorithmsWPA, WPA2-PSK

Management features

Behavior analysisIntrusion detection, Line crossing detection
Reset buttonYes

Power

Power source typeDC
DC output voltage12

Operational conditions

Operating temperature (T-T)-30 - 60 °C

Weight & dimensions

Width120 mm
Depth172 mm
Height198 mm

Features

Basic eventMotion Detection, Camera Tampering Detection, Exception

Sustainability

Compliance certificatesCE, RoHS

Packaging data

Package width163 mm
Package depth243 mm
Package height243 mm
Package weight1.21 kg

Packaging content

Number of cameras1
Mounting kitYes
