Samsung SNF-8010 security camera Dome IP security camera Indoor & outdoor

2560 x 2048 pixels Ceiling

Model SNF-8010EAN 730526355260

63 specifications

ConnectivityWired
TypeIP security camera
Weight780 g
ColourWhite
Form factorDome
Minimum illumination0.02 lx

See all specifications

Overview

Connectivity: Wired
Type: IP security camera
Weight: 780 g
Colour: White
Form factor: Dome
Minimum illumination: 0.02 lx

Brand: Samsung
Category: Security Camera
Model: SNF-8010
Part number: SNF-8010
EAN / UPC: 730526355260, 6950207326554, 8801089097644
Also known as: Samsung SNF-8010 security camera Dome IP security camera Indoor & outdoor 2560 x 2048 pixels Ceiling

Specifications

63 specifications in 19 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
PTZ control	Yes
Day/night mode	Yes
Alarm input/output	Yes
Languages support	Simplified Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, SER, Swedish, Turkish
Certification	UL, CE, FCC, Gost, KC (EN-61373, EN-50155 : SNF-8010VM)

Design

Specification	Value
Form factor	Dome
Mounting type	Ceiling
Product colour	White
International Protection (IP) code	IP66

Camera

Specification	Value
Minimum illumination	0.02 lx
Lens viewing angle, horizontal	187°
Lens viewing angle, vertical	187°
Lens viewing angle, diagonal	187°
White balance	ATW, AWC, Indoor, Manual, Outdoor
Camera shutter speed	2 - 1/12000 s

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 1.8 mm (1 / 1.8")
Progressive scan	Yes

Lens system

Specification	Value
Zoom capability	Yes
Digital zoom	16x

Video

Specification	Value
Maximum resolution	2560 x 2048 pixels
Total megapixels	6 MP
Video formats supported	H.264, M-JPEG
Supported graphics resolutions	320 x 240, 640 x 480 (VGA), 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 960, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2560 x 2048
Frame rate	20 fps
Noise reduction	Yes
Automatic gain control	Yes

Audio

Specification	Value
Audio formats supported	ADPCM, G.711, G.726
Signal-to-Noise Ratio (SNR)	60 dB

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Ethernet interface type	Fast Ethernet
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	TTCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Cabling technology	10/100Base-T(X)
Number of users	10 user(s)

Storage

Specification	Value
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1

Security

Specification	Value
IP address filtering	Yes
Motion sensor	Yes
Privacy protection	Yes
Video motion detection	Yes

Power

Specification	Value
Power source type	PoE
Power consumption (max)	8.7 W
Power consumption (Power over Ethernet (PoE))	10.3 W
DC output voltage	12
Power over Ethernet (PoE)	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	-30 - 55 °C
Storage temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 90%

System requirements

Specification	Value
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win
Mac operating systems supported	Mac OS X 10.7 Lion

Weight & dimensions

Specification	Value
Height	49.6 mm
Diameter	14.5 cm
Weight	780 g

Sustainability

Specification	Value
Compliance certificates	RoHS

Packaging data

Specification	Value
Package type	Box

Packaging content

Specification	Value
Number of cameras	1

Other features

Specification	Value
Noise detection	Yes
