Samsung SNB-6010P/EX security camera Box IP security camera Indoor & outdoor

1920 x 1080 pixels

Model SNB-6010P/EX

59 specifications

Overview

Brand: Samsung
Category: Security Camera
Model: SNB-6010P/EX
Part number: SNB-6010P/EX
Also known as: Samsung SNB-6010P/EX security camera Box IP security camera Indoor & outdoor 1920 x 1080 pixels

59 specifications in 14 groups

Specification	Value
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Alarm input/output	Yes
Languages support	Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, SER, Swedish, Turkish

Specification	Value
Minimum illumination	0.5 lx
Lens viewing angle, horizontal	71°
Lens viewing angle, vertical	38°
White balance	ATW, AWC, Manual, Outdoor
Camera shutter type	Electronic
Camera shutter speed	1/10000 s

Specification	Value
Sensor type	CMOS
Progressive scan	Yes

Specification	Value
Maximum aperture number	2.5
Fixed focal length	4.6 mm

Specification	Value
Maximum resolution	1920 x 1080 pixels
Total megapixels	2.38 MP
Video compression formats	H.264
Supported graphics resolutions	320 x 180, 320 x 240, 640 x 480 (VGA), 800 x 450, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 960
Supported video modes	720p, 1080p
Frame rate	30 fps
Noise reduction	Yes
Flip & mirror	Yes
Full HD	Yes
Privacy masking	Yes

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Supported network protocols	TTCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Cabling technology	10/100/1000Base-T(X)
Number of users	15 user(s)

Specification	Value
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes

Specification	Value
Power source type	PoE
Power consumption (max)	6.5 W
Power consumption (Power over Ethernet (PoE))	7.5 W
DC output voltage	12
Power over Ethernet (PoE)	Yes

Specification	Value
Operating temperature (T-T)	-10 - 55 °C
Storage temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 90%

Specification	Value
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win
Mac operating systems supported	Mac OS X 10.7 Lion
