Samsung SNB-5004 security camera Bullet IP security camera Indoor

1384 x 1076 pixels

Model SNB-5004EAN 6950207322945

57 specifications

ConnectivityWired
TypeIP security camera
Weight395 g
ColourBlack, Ivory
Form factorBullet
Minimum illumination0.0008 lx

See all specifications

Overview

Connectivity: Wired
Type: IP security camera
Weight: 395 g
Colour: Black, Ivory
Form factor: Bullet
Minimum illumination: 0.0008 lx

Brand: Samsung
Category: Security Camera
Model: SNB-5004
Part number: SNB-5004
EAN / UPC: 6950207322945, 6950207325465
Also known as: Samsung SNB-5004 security camera Bullet IP security camera Indoor 1384 x 1076 pixels

Specifications

57 specifications in 16 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
PTZ control	No
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Alarm input/output	Yes
Plug and Play	Yes

Design

Specification	Value
Form factor	Bullet
Product colour	Black, Ivory
Housing material	Aluminium, Plastic

Camera

Specification	Value
Minimum illumination	0.0008 lx
White balance	ATW, Indoor, Manual, Outdoor
Camera shutter type	Electronic
Camera shutter speed	1/12000 - 2 s

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 3 mm (1 / 3")
Progressive scan	Yes

Night vision

Specification	Value
Night vision	Yes

Video

Specification	Value
Maximum resolution	1384 x 1076 pixels
Total megapixels	1.3 MP
Video formats supported	H.264, M-JPEG, MPEG
Supported graphics resolutions	320 x 240, 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Supported video modes	720p
Frame rate	60 fps

Audio

Specification	Value
Audio formats supported	ADPCM
Signal-to-Noise Ratio (SNR)	50 dB
Audio detection	Yes

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Supported network protocols	TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, Onvif
Cabling technology	10/100Base-T(X)

Storage

Specification	Value
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
RS-485 ports	1
Composite video out	1
Microphone in	Yes
Headphone outputs	1
DC-in jack	Yes
Interface	RJ-45

Security

Specification	Value
Motion sensor	Yes
Video motion detection	Yes

Power

Specification	Value
Power source type	PoE
AC input voltage	12-24 V
Power consumption (typical)	12.5 W
Power over Ethernet (PoE)	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	0 - 90%

System requirements

Specification	Value
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Win
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Weight & dimensions

Specification	Value
Width	73.1 mm
Depth	66.6 mm
Height	147.8 mm
Weight	395 g

Packaging content

Specification	Value
Bundled software	SmartViewer 4.0
