LevelOne GEMINI Varifocal IP Network Camera, 5-Megapixel, IR LEDs, two-way audio, 802.3af PoE, Indoor/Outdoor

LevelOne GEMINI Varifocal IP Network Camera, 5-Megapixel, IR LEDs, two-way audio, 802.3af PoE, Indoor/Outdoor

Model FCS-5068EAN 4015867199220

94 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight1.2 kg
  • ColourWhite
  • Form factorBullet
  • Minimum illumination0.01 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
1.2 kg
Colour
White
Form factor
Bullet
Minimum illumination
0.01 lx
Brand
LevelOne
Model
FCS-5068
Part number
FCS-5068
EAN / UPC
4015867199220
Also known as
LevelOne GEMINI Varifocal IP Network Camera, 5-Megapixel, IR LEDs, two-way audio, 802.3af PoE, Indoor/Outdoor

Specifications

94 specifications in 22 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Infrared (IR) cut-off filterYes
Alarm input/outputYes
CertificationCE,FCC,UL

Design

Form factorBullet
Mounting typeCeiling/wall
Product colourWhite
International Protection (IP) codeIP66
WeatherproofYes
Country of originChina

Camera

Minimum illumination0.01 lx
Field of view (FOV) angle106°
Camera shutter speed1/3 - 1/10000 s

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 3 mm (1 / 3")
Progressive scanYes

Lens system

Focal length range2.8 - 12 mm
Maximum aperture number1.4

Night vision

Night visionYes
Night vision distance30 m
LED typeIR

Video

Maximum resolution2560 x 1920 pixels
Total megapixels5 MP
Video formats supportedAVI
Video compression formatsH.264, H.264+, M-JPEG
Supported graphics resolutions1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2560 x 1920
Frame rate30 fps
Back Light Compensation (BLC)Yes
Flip & mirrorYes
Image quality adjustmentBrightness, Saturation
Privacy maskingYes
Region of Interest (ROI) encodingYes

Audio

Audio system2-way
Audio input channels1.0 channels
Audio output channels1.0 channels
Audio formats supportedG.711, G.726
Audio codecsG.711/G.722.1/G.726/MP2L2

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4,TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Cabling technology10/100Base-T(X)
Number of users20 user(s)
Quality of Service (QoS) supportYes

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsSD, SDHC, SDXC
Maximum memory card size128 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
Composite video out1
DC-in jackYes
InterfaceRJ-45

Security

Password protectionYes
Anti-flickerYes
Digital watermarkYes
IP address filteringYes
MirrorYes
Video motion detectionYes

Management features

Web browserYes
Behavior analysisLine crossing detection

Power

Power source typePoE
Power consumption (max)5.5 W
DC output voltage12
Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)-30 - 60 °C
Operating relative humidity (H-H)0 - 95%

System requirements

Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight & dimensions

Width105 mm
Depth258.6 mm
Height95 mm
Weight1.2 kg

Packaging data

Package width386 mm
Package depth156 mm
Package height155 mm
Package weight1.33 kg
Package typeBox

Packaging content

Number of cameras1
Screws includedYes
ManualYes
Resource CDYes

Other features

Browser supportedInternet Explorer 9+
Data transfer rate16 Mbit/s

Technical details

IrisYes

Logistics data

Harmonized System (HS) code85258900
Master (outer) case width490 mm
Master (outer) case length400 mm
Master (outer) case height500 mm
Master (outer) case gross weight11.9 kg
Products per master (outer) case9 pc(s)
