LevelOne GEMINI Varifocal IP Network Camera, 2-Megapixel, IR LEDs, two-way audio, 802.3af PoE, Indoor/Outdoor
Model FCS-5059EAN 4015867198100
94 specifications
- ConnectivityWired
- TypeIP security camera
- Weight1.2 kg
- ColourWhite
- Form factorBullet
- Minimum illumination0.01 lx
Overview
- Connectivity
- Wired
- Type
- IP security camera
- Weight
- 1.2 kg
- Colour
- White
- Form factor
- Bullet
- Minimum illumination
- 0.01 lx
- Brand
- LevelOne
- Category
- Security Camera
- Model
- FCS-5059
- Part number
- FCS-5059
- EAN / UPC
- 4015867198100
- Also known as
- LevelOne GEMINI Varifocal IP Network Camera, 2-Megapixel, IR LEDs, two-way audio, 802.3af PoE, Indoor/Outdoor
Specifications
94 specifications in 22 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Alarm input/output | Yes |
| Certification | CE, FCC, UL, ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI,ISO-9001 |
Design
| Specification | Value |
|---|---|
| Form factor | Bullet |
| Mounting type | Ceiling/wall |
| Product colour | White |
| International Protection (IP) code | IP66 |
| Weatherproof | Yes |
| Country of origin | China |
Camera
| Specification | Value |
|---|---|
| Minimum illumination | 0.01 lx |
| Field of view (FOV) angle | 106° |
| White balance | Auto |
| Camera shutter speed | 1/3 - 1/10000 s |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 1 |
| Focal length range | 2.8 - 12 mm |
| Fixed focal length | 1.4 mm |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 1920 x 1080 pixels |
| Total megapixels | 2 MP |
| Video formats supported | AVI |
| Video compression formats | H.265, M-JPEG |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Noise reduction | Yes |
| Automatic gain control | Yes |
| Back Light Compensation (BLC) | Yes |
| Flip & mirror | Yes |
| Full HD | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Portrait mode | Yes |
| Privacy masking | Yes |
| Text caption overlay | Yes |
| Time stamp overlay | Yes |
Audio
| Specification | Value |
|---|---|
| Audio system | 2-way |
| Audio formats supported | G.711, G.726 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3u |
| Supported network protocols | IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP, IGMP, SNMP, Unicast |
| Cabling technology | 10/100Base-T(X) |
| Number of users | 20 user(s) |
| Quality of Service (QoS) support | Yes |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSDHC, MicroSDXC |
| Maximum memory card size | 128 GB |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Composite video out | 1 |
| DC-in jack | Yes |
Security
| Specification | Value |
|---|---|
| Password protection type | User |
| IP address filtering | Yes |
| Video motion detection | Yes |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Reset button | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | PoE |
| AC input voltage | 12 V |
| Power consumption (max) | 7.5 W |
| Power consumption (Power over Ethernet (PoE)) | 5.5 W |
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -30 - 60 °C |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 105 mm |
| Depth | 258.6 mm |
| Height | 95 mm |
| Weight | 1.2 kg |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | RoHS |
Packaging data
| Specification | Value |
|---|---|
| Package width | 386 mm |
| Package depth | 156 mm |
| Package height | 155 mm |
| Package weight | 1.82 kg |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
| Screws included | Yes |
| Resource CD | Yes |
Technical details
| Specification | Value |
|---|---|
| Audio input | Yes |
| Removable IR-cut filter | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85258900 |
| Master (outer) case width | 490 mm |
| Master (outer) case length | 400 mm |
| Master (outer) case height | 500 mm |
| Master (outer) case gross weight | 11.9 kg |
| Products per master (outer) case | 9 pc(s) |
