LevelOne HUBBLE Fixed IP Network Camera, 3-Megapixel, 802.3af PoE, IR LEDs, Indoor/Outdoor
Model FCS-5053EAN 4015867190067
82 specifications
- ConnectivityWired
- TypeIP security camera
- Weight578 g
- ColourSilver
- Form factorBullet
- Minimum illumination0.1 lx
Overview
- Connectivity
- Wired
- Type
- IP security camera
- Weight
- 578 g
- Colour
- Silver
- Form factor
- Bullet
- Minimum illumination
- 0.1 lx
- Brand
- LevelOne
- Category
- Security Camera
- Model
- FCS-5053
- Part number
- FCS-5053
- EAN / UPC
- 4015867190067
- Also known as
- LevelOne HUBBLE Fixed IP Network Camera, 3-Megapixel, 802.3af PoE, IR LEDs, Indoor/Outdoor
Specifications
82 specifications in 20 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Outdoor |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Day/night mode | Yes |
| Certification | CE, FCC, ONVIF, IP66 |
Design
| Specification | Value |
|---|---|
| Form factor | Bullet |
| Mounting type | Wall |
| Product colour | Silver |
| International Protection (IP) code | IP66 |
| Weatherproof | Yes |
| Country of origin | Taiwan |
Camera
| Specification | Value |
|---|---|
| Minimum illumination | 0.1 lx |
| Lens viewing angle, horizontal | 62.7° |
| White balance | Auto |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/5 - 1/10000 s |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 3.2 mm (1 / 3.2") |
| Progressive scan | Yes |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 1 |
| Zoom capability | Yes |
| Fixed focus | Yes |
| Fixed focal length | 4.2 mm |
| Focus adjustment | 1.8 |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 20 m |
| LED type | IR |
| Number of illumination LEDs | 1 |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 2048 x 1536 pixels |
| Total megapixels | 3 MP |
| Video formats supported | Raw |
| Video compression formats | H.264, M-JPEG |
| Supported graphics resolutions | 320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA) |
| Supported video modes | 240p, 480p, 720p, 1080p |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Noise reduction | Yes |
| Automatic gain control | Yes |
| Back Light Compensation (BLC) | Yes |
| Full HD | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet interface type | Fast Ethernet |
| Supported network protocols | TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Maximum memory card size | 64 GB |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Interface | RJ-45 |
Power
| Specification | Value |
|---|---|
| Power source type | PoE |
| Power consumption (typical) | 4.88 W |
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 50 °C |
| Operating relative humidity (H-H) | 10 - 85% |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 77 mm |
| Depth | 175 mm |
| Height | 71 mm |
| Weight | 578 g |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Packaging data
| Specification | Value |
|---|---|
| Package width | 232 mm |
| Package depth | 202 mm |
| Package height | 95 mm |
| Package weight | 476 g |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
| Quick installation guide | Yes |
| Resource CD | Yes |
| Wall mounting kit | Yes |
Technical details
| Specification | Value |
|---|---|
| Iris | Yes |
| Back light compensation method | Yes |
| Number of video streams | 2 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85258900 |
| Master (outer) case width | 484 mm |
| Master (outer) case length | 301 mm |
| Master (outer) case height | 418 mm |
| Master (outer) case gross weight | 13.7 kg |
| Products per master (outer) case | 12 pc(s) |
