LevelOne Zoom Network camera, 2-Megapixel, Outdoor, 802.3af PoE, Day & Night, IR LEDs, 10x Optical Zoom

LevelOne Zoom Network camera, 2-Megapixel, Outdoor, 802.3af PoE, Day & Night, IR LEDs, 10x Optical Zoom

Model FCS-5042Part no. FCS-5043EAN 4015867191361

96 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight800 g
  • ColourWhite
  • Form factorBullet
  • Minimum illumination1 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
800 g
Colour
White
Form factor
Bullet
Minimum illumination
1 lx
Brand
LevelOne
Model
FCS-5042
Part numbers
FCS-5043, FCS-5042
EAN / UPC
4015867191361, 846359022344, 846359032725, 4015867182697 +3 more
Also known as
LevelOne Zoom Network camera, 2-Megapixel, Outdoor, 802.3af PoE, Day & Night, IR LEDs, 10x Optical Zoom

Specifications

96 specifications in 22 groups

Performance

TypeIP security camera
Placement supportedOutdoor
Connectivity technologyWired
PTZ controlYes
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Infrared (IR) cut-off filterYes
CertificationCE, FCC, Onvif

Design

Form factorBullet
Mounting typeCeiling/wall
Product colourWhite
LED indicatorsActivity, Link
International Protection (IP) codeIP66
WeatherproofYes
Country of originTaiwan

Camera

Minimum illumination1 lx
Field of view (FOV) angle66.6°
White balanceAuto
Camera shutter typeElectronic
Camera shutter speed1 - 1/10000 s

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 2.7 mm (1 / 2.7")
Progressive scanYes

Lens system

Zoom capabilityYes
Optical zoom10x
Digital zoom4x
Focal length range4.9 - 49 mm
Auto focusYes
Focus adjustment1.8 - 3.0

Night vision

Night visionYes
Night vision distance30 m
LED typeIR
Number of illumination LEDs4

Video

Maximum resolution1920 x 1080 pixels
Total megapixels2 MP
Video formats supportedMPEG4
Video compression formatsH.264, M-JPEG, MPEG4
Supported video modes1080p
Frame rate25 fps
Noise reductionYes
Automatic gain controlYes
Flip & mirrorYes
Full HDYes
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
Time stamp overlayYes

Audio

Audio system2-way
Audio formats supportedG.711
Built-in microphoneNo
Voice codecsAMR, G.711

Network

Ethernet LANYes
Wi-FiNo
Networking standardsIEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocolsTCP/IPv4, HTTP, SMTP, FTP, DDNS, UPnP, NTP, PPPoE, DNS, DHCP, RTSP, Samba
Cabling technology10/100/1000Base-T(X)

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash), MicroSDHC
Maximum memory card size64 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
BNC output ports1
Microphone inYes
Headphone outputs1
Terminal block portYes
DC-in jackYes
InterfaceBNC

Security

Password protection typeUser
HTTPS encryptionYes
IP address filteringYes
Motion sensorYes

Management features

Reset buttonYes

Power

Power source typePoE
Power consumption (typical)10 W
DC output voltage12
DC output current1.5 A
Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)-20 - 50 °C
Storage temperature (T-T)10 - 85 °C

System requirements

Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win

Weight & dimensions

Width75 mm
Depth165 mm
Height75 mm
Weight800 g

Sustainability

Compliance certificatesRoHS

Packaging data

Package width270 mm
Package depth205 mm
Package height135 mm
Package weight1.3 kg
Package typeBox

Packaging content

Mounting kitYes
Screws includedYes
ManualYes
AC adapter includedYes
Quick installation guideYes
Resource CDYes

Technical details

IrisYes

Logistics data

Harmonized System (HS) code85258900
