LevelOne PT Dome Network Camera, 2-Megapixel, 802.3af PoE, Day & Night, IR LEDs

LevelOne PT Dome Network Camera, 2-Megapixel, 802.3af PoE, Day & Night, IR LEDs

Model FCS-4101EAN 846359032213

87 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight400 g
  • ColourBlack, White
  • Form factorDome
  • Minimum illumination1 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
400 g
Colour
Black, White
Form factor
Dome
Minimum illumination
1 lx
Brand
LevelOne
Model
FCS-4101
Part number
FCS-4101
EAN / UPC
846359032213, 4015867186688, 8463590322136
Also known as
LevelOne PT Dome Network Camera, 2-Megapixel, 802.3af PoE, Day & Night, IR LEDs

Specifications

87 specifications in 21 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
PTZ controlYes
Auto pan modeYes
Auto patrol modeYes
Wide Dynamic Range (WDR)Yes
Day/night modeYes
CertificationCE, FCC, Onvif

Design

Form factorDome
Mounting typeCeiling/Desk
Product colourBlack, White
LED indicatorsLink, Power
Country of originTaiwan

Camera

Minimum illumination1 lx
Tilt angle range0 - 70°
Pan range0 - 200°
White balanceAuto
Camera shutter typeElectronic
Camera shutter speed1/30 - 1/1000000 s

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 2.7 mm (1 / 2.7")
Progressive scanYes

Lens system

Zoom capabilityYes
Fixed focal length4 mm
Focus adjustment2.0

Night vision

Night visionYes
Night vision distance10 m
LED typeIR
Number of illumination LEDs19

Video

Maximum resolution1920 x 1080 pixels
Total megapixels2 MP
Video formats supportedMPEG4
Video compression formatsH.264, M-JPEG, MPEG4
Supported graphics resolutions320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Supported video modes240p, 480p, 720p, 1080p
Frame rate30 fps
Noise reductionYes
Automatic gain controlYes
Flip & mirrorYes
Full HDYes
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
Time stamp overlayYes

Audio

Audio system1-way
Built-in microphoneYes
Voice codecsAMR

Network

Ethernet LANYes
Wi-FiNo
Ethernet interface typeFast Ethernet
Networking standardsIEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocolsTCP/IP, HTTP, SMTP, FTP, DDNS, UPnP, NTP, PPPoE, DNS, DHCP, RTSP, Samba

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash), MicroSDHC
Maximum memory card size64 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
DC-in jackYes
InterfaceRJ-45

Security

Password protection typeUser
HTTPS encryptionYes
IP address filteringYes
Motion sensorYes

Management features

Reset buttonYes

Power

Power source typePoE
AC input voltage24 V
Power consumption (typical)8 W
DC output current1.5 A
Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80%

System requirements

Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win

Weight & dimensions

Width63 mm
Depth63 mm
Height92 mm
Weight400 g

Sustainability

Compliance certificatesRoHS

Packaging data

Package width205 mm
Package depth155 mm
Package height90 mm
Package weight700 g
Package typeBox

Packaging content

Mounting kitYes
Screws includedYes
ManualYes
AC adapter includedYes
Quick installation guideYes

Technical details

Number of video streams2
