LevelOne HUBBLE PTZ IP Network Camera, 2-Megapixel, IR LEDs, Indoor/Outdoor, 33X Optical Zoom, Vandalproof

LevelOne HUBBLE PTZ IP Network Camera, 2-Megapixel, IR LEDs, Indoor/Outdoor, 33X Optical Zoom, Vandalproof

Model FCS-4048EAN 4015867203873

85 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight2.75 kg
  • ColourBlack, White
  • Form factorDome
  • Minimum illumination0 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
2.75 kg
Colour
Black, White
Form factor
Dome
Minimum illumination
0 lx
Brand
LevelOne
Model
FCS-4048
Part number
FCS-4048
EAN / UPC
4015867203873
Also known as
LevelOne HUBBLE PTZ IP Network Camera, 2-Megapixel, IR LEDs, Indoor/Outdoor, 33X Optical Zoom, Vandalproof

Specifications

85 specifications in 21 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
PTZ controlYes
Day/night modeYes
CertificationCF/FCC

Design

Form factorDome
Mounting typeCeiling
Product colourBlack, White
LED indicatorsPower
Protection featuresVandal proof
International Protection (IP) codeIP66
IK codeIK10
WeatherproofYes
Country of originTaiwan

Camera

Minimum illumination0 lx
Field of view (FOV) angle61.7°
Tilt speed280 °/sec
Pan preset speed280 °/sec
Camera shutter speed1/5 - 1/10000 s
Adjustment shutter speedAuto/Manual

Image sensor

Optical sensor size25.4 / 2.8 mm (1 / 2.8")

Lens system

Zoom capabilityYes
Optical zoom33x
Focal length range4.5 - 148.5 mm
Maximum aperture number5
Minimum aperture number1.6

Night vision

Night visionYes
Night vision distance150 m
LED typeIR

Video

Maximum resolution1920 x 1080 pixels
Total megapixels2 MP
Video formats supportedRaw
Video compression formatsH.264, M-JPEG
Supported graphics resolutions320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Supported video modes240p, 480p, 720p, 1080p
Frame rate60 fps
Full HDYes

Audio

Audio input channels1.0 channels
Audio output channels1.0 channels
Audio codecsG.711
Sample rate8 kHz

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Supported network protocolsTCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv4, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour
Number of users16 user(s)

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash), SD
Maximum memory card size64 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
Terminal block portYes

Security

Password protection typeUser
HTTPS encryptionYes
IP address filteringYes
Video motion detectionYes

Management features

Reset buttonYes

Power

Power source typePoE
AC input voltage24 V
Power consumption (typical)25 W
Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)-40 - 50 °C
Operating relative humidity (H-H)10 - 85%

System requirements

Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight & dimensions

Width191 mm
Depth191 mm
Height282 mm
Weight2.75 kg

Packaging data

Package width289 mm
Package depth246 mm
Package height289 mm
Package weight2 kg
Package typeBox

Packaging content

Number of cameras1
AC adapter includedYes
Resource CDYes

Other features

Browser supportedMicrosoft Internet Explorer 8.0

Logistics data

Harmonized System (HS) code85258900
Master (outer) case width525 mm
Master (outer) case length565 mm
Master (outer) case height445 mm
Master (outer) case gross weight20.7 kg
Products per master (outer) case4 pc(s)
