LevelOne PTZ Dome Network Camera, 2-Megapixel, Outdoor, 802.3at PoE+, Day & Night, 18x Optical Zoom, WDR
Model FCS-4041EAN 846359019788
85 specifications
- ConnectivityWired
- TypeIP security camera
- Weight2.32 kg
- ColourBlack, White
- Form factorDome
- Minimum illumination0.04 lx
Overview
- Connectivity
- Wired
- Type
- IP security camera
- Weight
- 2.32 kg
- Colour
- Black, White
- Form factor
- Dome
- Minimum illumination
- 0.04 lx
- Brand
- LevelOne
- Category
- Security Camera
- Model
- FCS-4041
- Part number
- FCS-4041
- EAN / UPC
- 846359019788, 4015867160268
- Also known as
- LevelOne PTZ Dome Network Camera, 2-Megapixel, Outdoor, 802.3at PoE+, Day & Night, 18x Optical Zoom, WDR
Specifications
85 specifications in 18 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Outdoor |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Auto pan mode | Yes |
| Auto patrol mode | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Certification | CE, FCC, ONVIF |
Design
| Specification | Value |
|---|---|
| Form factor | Dome |
| Mounting type | Wall |
| Product colour | Black, White |
| LED indicators | Activity, Power |
| International Protection (IP) code | IP66 |
| Weatherproof | Yes |
| Country of origin | Taiwan |
Camera
| Specification | Value |
|---|---|
| Minimum illumination | 0.04 lx |
| Lens viewing angle, horizontal | 55.2° |
| Tilt angle range | -10 - 190° |
| Tilt speed | 45 °/sec |
| Pan range | 0 - 360° |
| Pan speed | 87 °/sec |
| White balance | Auto |
| Camera shutter speed | 1/30 - 1/30000 s |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Progressive scan | Yes |
Lens system
| Specification | Value |
|---|---|
| Zoom capability | Yes |
| Optical zoom | 18x |
| Focal length range | 4.7 - 84.6 mm |
| Auto focus | Yes |
| Focus adjustment | 1.6 - 2.8 |
| Normal focusing range | 1 m |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 1920 x 1080 pixels |
| Total megapixels | 2 MP |
| Video formats supported | AVI |
| Video compression formats | H.264, M-JPEG |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
| Supported video modes | 720p, 1080p |
| Frame rate | 60 fps |
| Analog signal format system | NTSC, PAL |
| Noise reduction | Yes |
| Automatic gain control | Yes |
| Flip & mirror | Yes |
| Full HD | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Portrait mode | Yes |
| Privacy masking | Yes |
| Text caption overlay | Yes |
| Time stamp overlay | Yes |
Audio
| Specification | Value |
|---|---|
| Audio system | 2-way |
| Built-in microphone | No |
| Voice codecs | G.711, G.726 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Supported network protocols | IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP, IGMP, SNMP, IEEE 802.1x, IEEE 802.3at |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC |
| Maximum memory card size | 32 GB |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Interface | RJ-45 |
Security
| Specification | Value |
|---|---|
| Motion sensor | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | PoE |
| AC input voltage | 24 V |
| Power consumption (max) | 65 W |
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 50 °C |
| Operating relative humidity (H-H) | 10 - 85% |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 192 mm |
| Depth | 282 mm |
| Height | 192 mm |
| Weight | 2.32 kg |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Packaging content
| Specification | Value |
|---|---|
| Mounting kit | Yes |
| Screws included | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Quick installation guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Iris | Yes |
| Back light compensation method | Yes |
| Number of video streams | 2 |
