GEMINI Fixed Dome IP Network Camera, 4-Megapixel, H.265, 802.3af PoE, IR LEDs, Indoor/Outdoor
Model FCS-3403EAN 846359052723
96 specifications
- ConnectivityWired
- TypeIP security camera
- Weight500 g
- ColourWhite
- Form factorDome
- Minimum illumination0 lx
Overview
- Connectivity
- Wired
- Type
- IP security camera
- Weight
- 500 g
- Colour
- White
- Form factor
- Dome
- Minimum illumination
- 0 lx
- Brand
- LevelOne
- Category
- Security Camera
- Model
- FCS-3403
- Part number
- FCS-3403
- EAN / UPC
- 846359052723, 4015867207703, 4015867235638
- Also known as
- LevelOne GEMINI Fixed Dome IP Network Camera, 4-Megapixel, H.265, 802.3af PoE, IR LEDs, Indoor/Outdoor
Specifications
96 specifications in 22 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| Wide Dynamic Range (WDR) | Yes |
| Infrared (IR) cut-off filter | Yes |
Design
| Specification | Value |
|---|---|
| Form factor | Dome |
| Mounting type | Ceiling |
| Product colour | White |
| Protection features | Dust resistant, Heat resistant, Rain proof, Snow resistant |
| International Protection (IP) code | IP67 |
| IK code | IK10 |
| Weatherproof | Yes |
| Country of origin | China |
Camera
| Specification | Value |
|---|---|
| Minimum illumination | 0 lx |
| Lens viewing angle, horizontal | 86° |
| Lens viewing angle, vertical | 46° |
| Lens viewing angle, diagonal | 102° |
| Camera shutter speed | 1/3 - 1/100000 s |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Progressive scan | Yes |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 1 |
| Fixed focal length | 4 mm |
| Focus adjustment | 2.0 |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 2680 x 1520 pixels |
| Total megapixels | 4 MP |
| Video formats supported | H.264, H.265, M-JPEG |
| Supported graphics resolutions | 320 x 240, 352 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2688 x 1520 |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Image stabilizer | Yes |
| Back Light Compensation (BLC) | Yes |
| Flip & mirror | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Portrait mode | Yes |
| Privacy masking | Yes |
| Text caption overlay | Yes |
| Time stamp overlay | Yes |
Audio
| Specification | Value |
|---|---|
| Audio formats supported | G.711 A-law, G.711 μ-law, G.722.1, G.726, MP2L2, PCM |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Networking standards | IEEE 802.1af |
| Supported network protocols | IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP,IGMP,SNMP |
| Number of users | 32 user(s) |
| Quality of Service (QoS) support | Yes |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Maximum memory card size | 128 GB |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
Security
| Specification | Value |
|---|---|
| Password protection | Yes |
| Active tampering alarm | Yes |
| Anti-flicker | Yes |
| Digital watermark | Yes |
| Heartbeat | Yes |
| IP address filtering | Yes |
| Mirror | Yes |
| Motion sensor | Yes |
| Video motion detection | Yes |
Management features
| Specification | Value |
|---|---|
| Reset button | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC, PoE |
| Power consumption (max) | 8.5 W |
| Power consumption (Power over Ethernet (PoE)) | 10 W |
| DC output voltage | 12 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Height | 82 mm |
| Diameter | 11.1 cm |
| Weight | 500 g |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Packaging data
| Specification | Value |
|---|---|
| Package width | 134 mm |
| Package depth | 134 mm |
| Package height | 108 mm |
| Package weight | 530 g |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
| Screws included | Yes |
| Resource CD | Yes |
Other features
| Specification | Value |
|---|---|
| Browser supported | Internet Explorer 8 above,Safari 8.0 |
Technical details
| Specification | Value |
|---|---|
| Number of video streams | 3 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85258900 |
| Pallet net height | 150 cm |
| Pallet net length | 80 cm |
| Pallet net width | 120 cm |
| Master (outer) case width | 345 mm |
| Master (outer) case length | 590 mm |
| Master (outer) case height | 568 mm |
| Master (outer) case gross weight | 608 g |
| Products per master (outer) case | 24 pc(s) |
