LevelOne HUBBLE Panoramic Dome IP Network Camera, 5-Megapixel, 802.3af PoE, Vandalproof, Vibrationproof, Indoor/Outdoor

LevelOne HUBBLE Panoramic Dome IP Network Camera, 5-Megapixel, 802.3af PoE, Vandalproof, Vibrationproof, Indoor/Outdoor

Model FCS-3093EAN 4015867190487

86 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight492 g
  • ColourBlack, White
  • Form factorDome
  • Minimum illumination0.05 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
492 g
Colour
Black, White
Form factor
Dome
Minimum illumination
0.05 lx
Brand
LevelOne
Model
FCS-3093
Part number
FCS-3093
EAN / UPC
4015867190487
Also known as
LevelOne HUBBLE Panoramic Dome IP Network Camera, 5-Megapixel, 802.3af PoE, Vandalproof, Vibrationproof, Indoor/Outdoor

Specifications

86 specifications in 21 groups

Performance

TypeIP security camera
Placement supportedOutdoor
Connectivity technologyWired
PTZ controlYes
Wide Dynamic Range (WDR)Yes
CertificationCE, FCC, ONVIF, IP68, IK10, NEMA 4X, EN50155

Design

Form factorDome
Mounting typeCeiling
Product colourBlack, White
LED indicatorsPower
Protection featuresShock resistant
International Protection (IP) codeIP68
IK codeIK10
WeatherproofYes
Country of originTaiwan

Camera

Minimum illumination0.05 lx
White balanceAuto
Camera shutter typeElectronic
Camera shutter speed1/5 - 1/10000 s

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 3.2 mm (1 / 3.2")
Progressive scanYes

Lens system

Number of lenses1
Zoom capabilityYes
Fixed focusYes
Fixed focal length1.19 mm
Focus adjustment2.0

Night vision

Night visionNo

Video

Maximum resolution2592 x 1944 pixels
Total megapixels5 MP
Video formats supportedRaw
Video compression formatsH.264, M-JPEG
Supported graphics resolutions320 x 240, 640 x 480 (VGA), 2048 x 1536 (QXGA), 2592 x 1944
Supported video modes240p, 480p
Frame rate15 fps
Video streamingYes
Noise reductionYes
Automatic gain controlYes
Back Light Compensation (BLC)Yes
Full HDYes
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness

Audio

Audio system1-way
Built-in microphoneNo
Voice codecsG.711

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Networking standardsIEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocolsTCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size64 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
Microphone inYes
InterfaceRJ-45

Management features

Reset buttonYes

Power

Power source typePoE
Power consumption (Power over Ethernet (PoE))2.91 W
Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)10 - 85%

System requirements

Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win

Weight & dimensions

Width110 mm
Depth60 mm
Height110 mm
Weight492 g

Sustainability

Compliance certificatesRoHS

Packaging data

Package width200 mm
Package depth200 mm
Package height90 mm
Package weight308 g
Package typeBox

Packaging content

Number of cameras1
Screws includedYes
Quick installation guideYes
Resource CDYes

Technical details

IrisYes
Back light compensation methodYes
Number of video streams2

Logistics data

Master (outer) case width420 mm
Master (outer) case length420 mm
Master (outer) case height390 mm
Master (outer) case gross weight13.9 kg
Products per master (outer) case16 pc(s)
