LevelOne FCS-3089 security camera Dome Indoor

2048 x 1536 pixels Ceiling

Model FCS-3089EAN 4015867202289

62 specifications

ConnectivityWired
TypeDome
Weight500 g
ColourBlack, White
Placement supportedIndoor
Minimum illumination0.005 lx

See all specifications

Overview

Connectivity: Wired
Type: Dome
Weight: 500 g
Colour: Black, White
Placement supported: Indoor
Minimum illumination: 0.005 lx

Brand: LevelOne
Category: Security Camera
Model: FCS-3089
Part number: FCS-3089
EAN / UPC: 4015867202289
Also known as: LevelOne FCS-3089 security camera Dome Indoor 2048 x 1536 pixels Ceiling

Specifications

62 specifications in 21 groups

Performance

Specification	Value
Placement supported	Indoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Plug and Play	Yes
Certification	CF, FCC

Design

Specification	Value
Form factor	Dome
Mounting type	Ceiling
Product colour	Black, White
LED indicators	Power
International Protection (IP) code	IP67
Country of origin	China

Camera

Specification	Value
Minimum illumination	0.005 lx
Field of view (FOV) angle	78.7°
Camera shutter speed	1/3 ~ 1/10000 s

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 2.8 mm (1 / 2.8")
Progressive scan	Yes

Lens system

Specification	Value
Maximum aperture number	2

Night vision

Specification	Value
Night vision	Yes
Night vision distance	30 m

Video

Specification	Value
Maximum resolution	2048 x 1536 pixels
Video formats supported	H.265+, AVI, H.264, H.264+, H.265
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA)
Frame rate	30 fps

Audio

Specification	Value
Voice codecs	G.711, G.722.1, G.726

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Bluetooth	No
Ethernet interface type	Fast Ethernet
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
Number of users	16 user(s)
Quality of Service (QoS) support	Yes

Storage

Specification	Value
Built-in HDD	No
Compatible memory cards	MicroSDHC, MicroSDXC
Maximum memory card size	128 GB

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
Terminal block port	Yes

Management features

Specification	Value
Reset button	Yes

Power

Specification	Value
Power source type	PoE
Power consumption (typical)	7 W
Power over Ethernet (PoE)	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95%

System requirements

Specification	Value
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows

Weight & dimensions

Specification	Value
Height	82.4 mm
Diameter	11.1 cm
Weight	500 g

Sustainability

Specification	Value
Compliance certificates	RoHS

Packaging data

Specification	Value
Package width	134 mm
Package depth	134 mm
Package height	108 mm
Package weight	500 g
Package type	Box

Packaging content

Specification	Value
Number of cameras	1
Resource CD	Yes

Technical details

Specification	Value
Removable IR-cut filter	Yes

Logistics data

Specification	Value
Master (outer) case width	345 mm
Master (outer) case length	288 mm
Master (outer) case height	568 mm
Master (outer) case gross weight	608 g
Products per master (outer) case	24 pc(s)
