LevelOne Fixed Dome Network Camera, 2-Megapixel, 802.3af PoE

LevelOne Fixed Dome Network Camera, 2-Megapixel, 802.3af PoE

Model FCS-3071EAN 846359001301

70 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight180 g
  • ColourBlack, White
  • Form factorDome
  • Minimum illumination0.02 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
180 g
Colour
Black, White
Form factor
Dome
Minimum illumination
0.02 lx
Brand
LevelOne
Model
FCS-3071
Part number
FCS-3071
EAN / UPC
846359001301, 4014619235131, 4015867158043
Also known as
LevelOne Fixed Dome Network Camera, 2-Megapixel, 802.3af PoE

Specifications

70 specifications in 19 groups

Performance

TypeIP security camera
Placement supportedOutdoor
Connectivity technologyWired
PTZ controlYes
Wide Dynamic Range (WDR)Yes
CertificationCE, FCC

Design

Form factorDome
Product colourBlack, White
International Protection (IP) codeIP66
WeatherproofYes

Camera

Minimum illumination0.02 lx
Lens viewing angle, horizontal78°
White balanceAuto
Camera shutter typeElectronic
Camera shutter speed1 - 1/10000 s

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 2.7 mm (1 / 2.7")
Progressive scanYes

Lens system

Zoom capabilityYes
Digital zoom8x
Fixed focal length4 mm
Focus adjustment1.5

Night vision

Night visionNo

Video

Maximum resolution1920 x 1080 pixels
Total megapixels2 MP
Video compression formatsH.264, M-JPEG
Supported graphics resolutions352 x 288, 640 x 480 (VGA), 704 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Supported video modes480p, 720p, 1080p
Frame rate30 fps
Noise reductionYes
Automatic gain controlYes
Flip & mirrorYes
Full HDYes
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
Portrait modeYes
Privacy maskingYes
Text caption overlayYes
Time stamp overlayYes

Network

Ethernet LANYes
Wi-FiNo
Ethernet interface typeFast Ethernet
Networking standardsIEEE 802.1x, IEEE 802.3af
Supported network protocolsIPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP, IGMP, SNMP, QoS, ONVIF

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash), MicroSDHC

Ports & interfaces

Ethernet LAN (RJ-45) ports1
InterfaceRJ-45

Security

Password protection typeUser
Active tampering alarmYes
HTTPS encryptionYes
IP address filteringYes

Management features

Reset buttonYes

Power

Power source typePoE
Power consumption (max)3.5 W
Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)10 - 90%

System requirements

Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista

Weight & dimensions

Height50 mm
Diameter11.7 cm
Weight180 g

Packaging data

Package width210 mm
Package depth80 mm
Package height220 mm
Package weight500 g

Packaging content

ManualYes
Quick installation guideYes

Technical details

Back light compensation methodYes
Number of video streams4
