LevelOne HUBBLE Fixed Dome IP Network Camera, 3-Megapixel, 802.3af PoE, Vandalproof

LevelOne HUBBLE Fixed Dome IP Network Camera, 3-Megapixel, 802.3af PoE, Vandalproof

Model FCS-3054EAN 846359034392

79 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight201 g
  • ColourBlack, White
  • Form factorDome
  • Minimum illumination0.1 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
201 g
Colour
Black, White
Form factor
Dome
Minimum illumination
0.1 lx
Brand
LevelOne
Model
FCS-3054
Part number
FCS-3054
EAN / UPC
846359034392, 4015867189689, 4056203001357, 8463590343926
Also known as
LevelOne HUBBLE Fixed Dome IP Network Camera, 3-Megapixel, 802.3af PoE, Vandalproof

Specifications

79 specifications in 21 groups

Performance

TypeIP security camera
Connectivity technologyWired
PTZ controlYes
CertificationCE, FCC, IK08

Design

Form factorDome
Mounting typeCeiling/wall
Product colourBlack, White
LED indicatorsPower
Protection featuresVandal proof
Country of originTaiwan

Camera

Minimum illumination0.1 lx
Lens viewing angle, horizontal83.3°
White balanceAuto
Camera shutter typeElectronic
Camera shutter speed1/5 - 1/10000 s

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 3.2 mm (1 / 3.2")
Progressive scanYes

Lens system

Number of lenses1
Zoom capabilityYes
Fixed focusYes
Fixed focal length2.93 mm
Focus adjustment2.0

Night vision

Night visionNo

Video

Maximum resolution2048 x 1536 pixels
Total megapixels3 MP
Video formats supportedRaw
Video compression formatsH.264, M-JPEG
Supported graphics resolutions320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA)
Supported video modes240p, 480p, 720p, 1080p
Frame rate30 fps
Video streamingYes
Noise reductionYes
Automatic gain controlYes
Back Light Compensation (BLC)Yes
Full HDYes
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness

Audio

Built-in microphoneNo
Voice codecsG.711

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Supported network protocolsTCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size64 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
InterfaceRJ-45

Management features

Reset buttonYes

Power

Power source typePoE
Power consumption (typical)2.91 W
Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)10 - 85%

System requirements

Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win

Weight & dimensions

Width110 mm
Depth58 mm
Height110 mm
Weight201 g

Sustainability

Compliance certificatesRoHS

Packaging data

Package width169 mm
Package depth169 mm
Package height112 mm
Package weight199 g

Packaging content

Number of cameras1
Screws includedYes
Quick installation guideYes
Resource CDYes

Technical details

IrisYes
Back light compensation methodYes
Number of video streams2

Logistics data

Harmonized System (HS) code85258900
Master (outer) case width350 mm
Master (outer) case length350 mm
Master (outer) case height342 mm
Master (outer) case gross weight5.7 kg
Products per master (outer) case12 pc(s)
