LevelOne HUBBLE Fixed Dome IP Network Camera, 3-Megapixel, 802.3af PoE, IR LEDs

LevelOne HUBBLE Fixed Dome IP Network Camera, 3-Megapixel, 802.3af PoE, IR LEDs

Model FCS-3053EAN 846359034330

78 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight310 g
  • ColourBlack, White
  • Form factorDome
  • Minimum illumination0.1 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
310 g
Colour
Black, White
Form factor
Dome
Minimum illumination
0.1 lx
Brand
LevelOne
Model
FCS-3053
Part number
FCS-3053
EAN / UPC
846359034330, 4015867189658
Also known as
LevelOne HUBBLE Fixed Dome IP Network Camera, 3-Megapixel, 802.3af PoE, IR LEDs

Specifications

78 specifications in 21 groups

Performance

TypeIP security camera
Connectivity technologyWired
PTZ controlYes
Day/night modeYes
CertificationCE, FCC, ONVIF

Design

Form factorDome
Mounting typeCeiling/wall
Product colourBlack, White
LED indicatorsLink, Power
Country of originTaiwan

Camera

Minimum illumination0.1 lx
Lens viewing angle, horizontal72°
White balanceAuto
Camera shutter typeElectronic
Camera shutter speed1/5 - 1/10000 s

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 3.2 mm (1 / 3.2")
Progressive scanYes

Lens system

Number of lenses1
Zoom capabilityYes
Fixed focusYes
Fixed focal length3.6 mm
Focus adjustment1.8

Night vision

Night visionYes
Night vision distance20 m
LED typeIR
Number of illumination LEDs10

Video

Maximum resolution2048 x 1536 pixels
Total megapixels3 MP
Video formats supportedRaw
Video compression formatsH.264, M-JPEG
Supported graphics resolutions320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA)
Supported video modes240p, 480p, 720p, 1080p
Frame rate30 fps
Video streamingYes
Noise reductionYes
Automatic gain controlYes
Back Light Compensation (BLC)Yes
Full HDYes
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness

Audio

Built-in microphoneNo

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Supported network protocolsTCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour

Storage

Built-in HDDNo

Ports & interfaces

Ethernet LAN (RJ-45) ports1
InterfaceRJ-45

Management features

Reset buttonYes

Power

Power source typePoE
Power consumption (typical)6.02 W
Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)10 - 85%

System requirements

Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win

Weight & dimensions

Width128 mm
Depth99 mm
Height128 mm
Weight310 g

Sustainability

Compliance certificatesRoHS

Packaging data

Package width169 mm
Package depth169 mm
Package height169 mm
Package weight240 g
Package typeBox

Packaging content

Number of cameras1
Screws includedYes
Quick installation guideYes
Resource CDYes

Technical details

IrisYes
Back light compensation methodYes
Number of video streams2

Logistics data

Master (outer) case width350 mm
Master (outer) case length350 mm
Master (outer) case height342 mm
Master (outer) case gross weight5.3 kg
Products per master (outer) case8 pc(s)
