LevelOne Fixed Network Camera, 3-Megapixel, PoE 802.3af

Model FCS-0032EAN 4015867190944

65 specifications

ConnectivityWired
TypeIP security camera
Weight140 g
ColourWhite
Form factorCube
Minimum illumination0.1 lx

See all specifications

Overview

Connectivity: Wired
Type: IP security camera
Weight: 140 g
Colour: White
Form factor: Cube
Minimum illumination: 0.1 lx

Brand: LevelOne
Category: Security Camera
Model: FCS-0032
Part number: FCS-0032
EAN / UPC: 4015867190944, 5050914850920
Also known as: LevelOne Fixed Network Camera, 3-Megapixel, PoE 802.3af

Specifications

65 specifications in 20 groups

Performance

Specification	Value
Type	IP security camera
Connectivity technology	Wired
PTZ control	Yes
Wide Dynamic Range (WDR)	Yes
Certification	CE, FCC, ONVIF

Design

Specification	Value
Form factor	Cube
Mounting type	Ceiling/wall
Product colour	White

Camera

Specification	Value
Minimum illumination	0.1 lx
Lens viewing angle, horizontal	70.8°
White balance	Auto
Camera shutter type	Electronic
Camera shutter speed	1/5 - 1/10000 s

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 3.2 mm (1 / 3.2")
Progressive scan	Yes

Lens system

Specification	Value
Zoom capability	Yes
Fixed focal length	3.6 mm
Focus adjustment	2.0

Night vision

Specification	Value
Night vision	No

Video

Specification	Value
Maximum resolution	2048 x 1536 pixels
Total megapixels	3 MP
Video formats supported	Raw
Video compression formats	H.264, M-JPEG
Supported graphics resolutions	320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA)
Supported video modes	240p, 480p, 720p, 1080p
Frame rate	30 fps
Noise reduction	Yes
Automatic gain control	Yes
Full HD	Yes
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness

Audio

Specification	Value
Voice codecs	G.711

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour

Storage

Specification	Value
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	64 GB

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
Interface	RJ-45

Management features

Specification	Value
Reset button	Yes

Power

Specification	Value
Power source type	PoE
Power consumption (typical)	3.7 W
Power over Ethernet (PoE)	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	10 - 85%

System requirements

Specification	Value
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Win

Weight & dimensions

Specification	Value
Width	66.5 mm
Depth	38.7 mm
Height	104 mm
Weight	140 g

Sustainability

Specification	Value
Compliance certificates	RoHS

Packaging data

Specification	Value
Package width	100 mm
Package depth	91 mm
Package height	138 mm
Package weight	330 g

Packaging content

Specification	Value
Mounting kit	Yes
Mounting brackets included	Yes
Manual	Yes
Quick start guide	Yes

Technical details

Specification	Value
Iris	Yes
Back light compensation method	Yes
Number of video streams	2
