Intellinet 550482 security camera Box IP security camera Indoor

720 x 480 pixels Desk

Model 550482EAN 766623550482

63 specifications

ProcessorARM9
Memory32 MB
ConnectivityWired & Wireless
TypeIP security camera
Weight1.1 kg
ColourAluminium, Black

See all specifications

Overview

Processor: ARM9
Memory: 32 MB
Connectivity: Wired & Wireless
Type: IP security camera
Weight: 1.1 kg
Colour: Aluminium, Black

Brand: Intellinet
Category: Security Camera
Model: 550482
Part number: 550482
EAN / UPC: 766623550482
Also known as: Intellinet 550482 security camera Box IP security camera Indoor 720 x 480 pixels Desk

Specifications

63 specifications in 18 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
PTZ control	Yes
Antenna type	External
Antennas quantity	1
Antenna gain level (max)	2 dBi
Processor model	ARM9
Detachable antenna(s)	Yes
Certification	FCC Class B, RF: EN300328, EMC: EN301489-1/-7, EN60950-1

Design

Specification	Value
Form factor	Box
Mounting type	Desk
Product colour	Aluminium, Black
LED indicators	Network, Operation, Power

Camera

Specification	Value
Minimum illumination	0.1 lx
Field of view (FOV) angle	53°
White balance	Manual

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 3.2 mm (1 / 3.2")

Lens system

Specification	Value
Digital zoom	4.5x
Fixed focal length	6 mm

Night vision

Specification	Value
Night vision	No

Video

Specification	Value
Maximum resolution	720 x 480 pixels
Total megapixels	2 MP
Supported graphics resolutions	352 x 240, 640 x 480 (VGA), 720 x 480
Frame rate	25 fps
Analog signal format system	NTSC, PAL
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness

Audio

Specification	Value
Audio system full duplex	Yes
Sample rate	3.4 kHz
Signal-to-Noise Ratio (SNR)	42.3 dB

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	Yes
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocols	TCP/IP, UDP, HTTP, HTTPS, FTP, SMTP, DHCP, DNS, ARP, ICMP, RTSP, RTC
Wi-Fi standards	802.11b, 802.11g
Wi-Fi data rate (max)	54 Mbit/s
Number of users	50 user(s)

Storage

Specification	Value
Flash memory	8 MB
Internal memory	32 MB

Ports & interfaces

Specification	Value
Microphone in	Yes

Security

Specification	Value
Motion sensor	Yes
Video motion detection	Yes

Management features

Specification	Value
Web-based management	No

Power

Specification	Value
Power source type	PoE
Power consumption (max)	6 W
DC output voltage	12
DC output current	1.5 A
Power over Ethernet (PoE)	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	20 - 80%

System requirements

Specification	Value
Mac compatibility	Yes
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows Vista Business, Windows Vista Home Basic, Windows Vista Home Premium, Windows XP Home, Windows XP Professional
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Ma
Linux operating systems supported	Yes

Weight & dimensions

Specification	Value
Width	87 mm
Height	45 mm
Length	158 mm
Weight	1.1 kg

Packaging content

Specification	Value
Number of cameras	1
Manual	Yes
Resource CD	Yes
