Intellinet 550413 security camera Dome IP security camera Indoor & outdoor

720 x 576 pixels Ceiling

Model 550413EAN 766623550413

62 specifications

ProcessorARM9
Memory32 MB
ConnectivityWired
TypeIP security camera
Weight1 kg
ColourAluminium, Black

See all specifications

Overview

Processor: ARM9
Memory: 32 MB
Connectivity: Wired
Type: IP security camera
Weight: 1 kg
Colour: Aluminium, Black

Brand: Intellinet
Category: Security Camera
Model: 550413
Part number: 550413
EAN / UPC: 766623550413
Also known as: Intellinet 550413 security camera Dome IP security camera Indoor & outdoor 720 x 576 pixels Ceiling

Specifications

62 specifications in 18 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Day/night mode	Yes
Processor model	ARM9
Certification	FCC Class B, RF: EN300328, EMC: EN301489-1/-7, EN60950-1

Design

Specification	Value
Form factor	Dome
Mounting type	Ceiling
Product colour	Aluminium, Black
LED indicators	Network, Operation, Power
Housing material	Aluminium
Protection features	Vandal proof

Camera

Specification	Value
Minimum illumination	0 lx
White balance	Auto
Camera shutter speed	1/50 - 1/100000 s

Image sensor

Specification	Value
Sensor type	Super HAD CCD
Optical sensor size	25.4 / 3 mm (1 / 3")

Lens system

Specification	Value
Focal length range	4 - 9 mm

Night vision

Specification	Value
Night vision	Yes
Night vision distance	30 m
LED type	IR
Number of illumination LEDs	24

Video

Specification	Value
Maximum resolution	720 x 576 pixels
Supported graphics resolutions	352 x 288, 720 x 576
Frame rate	25 fps
Analog signal format system	PAL
Image quality adjustment	Brightness, Contrast, Saturation

Audio

Specification	Value
Audio system full duplex	Yes
Sample rate	3.4 kHz
Signal-to-Noise Ratio (SNR)	48 dB

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocols	TCP/IP, UDP, HTTP, HTTPS, FTP, SMTP, DHCP, DNS, ARP, ICMP, POP3, RTSP, RTC
Number of users	50 user(s)

Storage

Specification	Value
Flash memory	8 MB
Internal memory	32 MB

Ports & interfaces

Specification	Value
Microphone in	Yes

Security

Specification	Value
HTTPS encryption	Yes
Motion sensor	Yes
Video motion detection	Yes

Power

Specification	Value
Power source type	PoE
Power consumption (max)	3 W
DC output voltage	12
DC output current	1.5 A
Power over Ethernet (PoE)	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	-10 - 50 °C
Storage temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	20 - 80%

System requirements

Specification	Value
Mac compatibility	Yes
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows Vista Business, Windows Vista Home Basic, Windows Vista Home Premium, Windows XP Home, Windows XP Professional
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Ma
Linux operating systems supported	Yes

Weight & dimensions

Specification	Value
Height	110 mm
Diameter	16 cm
Weight	1 kg

Packaging content

Specification	Value
Number of cameras	1
Manual	Yes
Quick installation guide	Yes
Resource CD	Yes

Technical details

Specification	Value
Maximum output level	1 Vpp
Output impedance	75 Ω
