Intellinet 550291 security camera Box IP security camera Indoor

Intellinet 550291 security camera Box IP security camera Indoor

720 x 576 pixels Desk

Model 550291EAN 766623550291

56 specifications
  • ProcessorARM9
  • Memory32 MB
  • ConnectivityWired
  • TypeIP security camera
  • Weight1.1 kg
  • ColourBlack, Stainless steel
See all specifications

Overview

Processor
ARM9
Memory
32 MB
Connectivity
Wired
Type
IP security camera
Weight
1.1 kg
Colour
Black, Stainless steel
Brand
Intellinet
Model
550291
Part number
550291
EAN / UPC
766623550291
Also known as
Intellinet 550291 security camera Box IP security camera Indoor 720 x 576 pixels Desk

Specifications

56 specifications in 16 groups

Performance

TypeIP security camera
Placement supportedIndoor
Connectivity technologyWired
Day/night modeYes
Processor modelARM9
CertificationFCC Class B, RF: EN300328, EMC: EN301489-1/-7, Safety: EN60950-1

Design

Form factorBox
Mounting typeDesk
Product colourBlack, Stainless steel
LED indicatorsYes

Camera

Minimum illumination0 lx
Field of view (FOV) angle53°
White balanceAuto
Camera shutter speed1/50 - 1/10000 s

Image sensor

Sensor typeSuper HAD CCD
Optical sensor size25.4 / 3 mm (1 / 3")

Lens system

Maximum aperture number1.8
Fixed focal length6 mm

Night vision

Night visionYes
Night vision distance10 m
LED typeIR
Number of illumination LEDs12

Video

Maximum resolution720 x 576 pixels
Supported graphics resolutions352 x 288, 720 x 576
Frame rate25 fps
Analog signal format systemPAL
Image quality adjustmentBrightness, Contrast, Saturation

Audio

Audio system full duplexYes
Frequency range300 - 3400 Hz
Signal-to-Noise Ratio (SNR)48 dB

Network

Ethernet LANYes
Wi-FiNo
Networking standardsIEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocolsTCP/IP, UDP, HTTP, FTP, SMTP, DHCP, DNS, ARP, ICMP, POP3, RTSP, RTC

Storage

Flash memory8 MB
Internal memory32 MB

Power

Power source typePoE
Power consumption (max)3 W
DC output voltage12
DC output current1.5 A
Power over Ethernet (PoE)Yes

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)0 - 60 °C
Operating relative humidity (H-H)20 - 80%

System requirements

Mac compatibilityYes
Windows operating systems supportedYes
Linux operating systems supportedYes

Weight & dimensions

Width98 mm
Depth158 mm
Height45 mm
Weight1.1 kg

Packaging content

Number of cameras1
ManualYes
Resource CDYes

Technical details

Maximum output level1 Vpp
Output impedance75 Ω
