Turret
Model TurretPart no. IPC-T26EP-0280B-IMOUEAN 6939554983481
65 specifications
- ConnectivityWired & Wireless
- TypeIP security camera
- Weight352 g
- ColourWhite
- Form factorTurret
- Lens viewing angle, horizontal114°
Overview
- Connectivity
- Wired & Wireless
- Type
- IP security camera
- Weight
- 352 g
- Colour
- White
- Form factor
- Turret
- Lens viewing angle, horizontal
- 114°
- Brand
- Imou
- Category
- Security Camera
- Model
- Turret
- Part number
- IPC-T26EP-0280B-IMOU
- EAN / UPC
- 6939554983481
- Also known as
- Imou Turret
Specifications
65 specifications in 19 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired & Wireless |
| Maximum operating distance | 100 m |
| Built-in light | Yes |
| Antenna type | External |
| Antennas quantity | 2 |
| Certification | CE, FCC |
Design
| Specification | Value |
|---|---|
| Form factor | Turret |
| Mounting type | Ceiling/wall |
| Product colour | White |
| Housing material | Metal, Plastic |
| International Protection (IP) code | IP67 |
| Weatherproof | Yes |
Camera
| Specification | Value |
|---|---|
| Lens viewing angle, horizontal | 114° |
| Lens viewing angle, vertical | 59° |
| Lens viewing angle, diagonal | 135° |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Progressive scan | Yes |
Lens system
| Specification | Value |
|---|---|
| Zoom capability | Yes |
| Digital zoom | 16x |
| Fixed focal length | 2.8 mm |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 1920 x 1080 pixels |
| Total megapixels | 2 MP |
| Video compression formats | H.264, H.265 |
| Frame rate | 30 fps |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Audio system | 2-way |
| Built-in microphone | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | No |
| Supported network protocols | CGI, ONVIF |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Frequency band | 2.4 GHz |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Security
| Specification | Value |
|---|---|
| Built-in siren | Yes |
| Siren noise level | 110 dB |
| Video motion detection | Yes |
Management features
| Specification | Value |
|---|---|
| Reset button | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Power consumption (typical) | 7 W |
| DC output voltage | 12 |
| DC output current | 1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
System requirements
| Specification | Value |
|---|---|
| Mobile operating systems supported | Android, iOS |
Weight & dimensions
| Specification | Value |
|---|---|
| Height | 102.2 mm |
| Diameter | 11 cm |
| Weight | 352 g |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
| Mounting kit | Yes |
| Screws included | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Waterproof connector | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85258900 |
