Imou AOV Dual 5MP + 5MP

AOV Dual 5MP + 5MP

Model AOV Dual 5MP + 5MPPart no. IMOU-IPC-SA70F-10M1T2-EU/FSP008EAN 6937479641769

82 specifications

Battery10000 mAh
ConnectivityWireless
TypeIP security camera
Weight1.08 kg
ColourBlack, White
Form factorTurret

See all specifications

Overview

Battery: 10000 mAh
Connectivity: Wireless
Type: IP security camera
Weight: 1.08 kg
Colour: Black, White
Form factor: Turret

Brand: Imou
Category: Security Camera
Model: AOV Dual 5MP + 5MP
Part number: IMOU-IPC-SA70F-10M1T2-EU/FSP008
EAN / UPC: 6937479641769
Also known as: Imou AOV Dual kit 5MP+5MP (with SD 128GB and SIM card)

Specifications

82 specifications in 21 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wireless
PTZ control	Yes
Auto-tracking	Yes
Day/night mode	Yes
Built-in light	Yes
Antenna type	External
Antennas quantity	2

Design

Specification	Value
Form factor	Turret
Mounting type	Wall
Product colour	Black, White
Housing material	Plastic
Protection features	Waterproof, Weatherproof
Weatherproof	Yes

Camera

Specification	Value
Lens viewing angle, horizontal	76°
Lens viewing angle, vertical	41°
Lens viewing angle, diagonal	91°
Tilt angle range	0 - 90°
Pan range	0 - 340°

Image sensor

Specification	Value
Sensor type	CMOS
Number of sensors	2
Optical sensor size	25.4 / 3 mm (1 / 3")
Progressive scan	Yes

Lens system

Specification	Value
Zoom capability	Yes
Digital zoom	8x
Fixed focal length	3.6 mm

Night vision

Specification	Value
Night vision	Yes
Night vision distance	25 m
LED type	IR/White

Video

Specification	Value
Maximum resolution	2880 x 1620 pixels
Total megapixels	10 MP
Video compression formats	H.264, H.265
Video recording	Yes
Frame rate	15 fps

Audio

Specification	Value
Built-in speaker(s)	Yes
Audio system	2-way
Built-in microphone	Yes

Network

Specification	Value
Ethernet LAN	No
Wi-Fi	Yes
Bluetooth	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax)
Frequency band	2.4 GHz
Mobile network connection	Yes
SIM card slot	Yes
SIM card type	NanoSIM
Mobile network generation	4G
4G standard	LTE-TDD & LTE-FDD

Storage

Specification	Value
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), SD
Maximum memory card size	512 GB

Ports & interfaces

Specification	Value
USB port	Yes

Security

Specification	Value
Built-in siren	Yes
Intelligent Video Surveillance (IVS) system features	Human detection, Vehicle detection

Management features

Specification	Value
Cloud-managed	No
Reset button	Yes

Power

Specification	Value
Power source type	Battery, DC, Solar
Power consumption (typical)	2 W
DC output current	5 A

Battery

Specification	Value
Battery capacity	10000 mAh
Rechargeable battery	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	-20 - 50 °C
Storage temperature (T-T)	-10 - 45 °C

System requirements

Specification	Value
Mobile operating systems supported	Android, iOS

Weight & dimensions

Specification	Value
Width	115 mm
Depth	195 mm
Height	193 mm
Weight	1.08 kg

Sustainability

Specification	Value
Compliance certificates	CE

Packaging data

Specification	Value
Package width	222 mm
Package depth	220 mm
Package height	300 mm
Package type	Box

Packaging content

Specification	Value
Number of cameras	1
Mounting kit	Yes
Mounting brackets included	Yes
Screws included	Yes
Memory card included	SD
Included memory card size	128 GB
Battery included	Yes
Quick start guide	Yes
