0070-08316-WIPER security camera Bulb IP security camera Indoor & outdoor
2592 x 1944 pixels Wall
Model 0070-08316-WIPEREAN 5715063078785
98 specifications
- ConnectivityWired
- TypeIP security camera
- Weight5.5 kg
- ColourBlack, White
- Form factorBulb
- Camera pan controlYes
Overview
- Connectivity
- Wired
- Type
- IP security camera
- Weight
- 5.5 kg
- Colour
- Black, White
- Form factor
- Bulb
- Camera pan control
- Yes
- Brand
- Ernitec
- Category
- Security Camera
- Model
- 0070-08316-WIPER
- Part number
- 0070-08316-WIPER
- EAN / UPC
- 5715063078785
- Also known as
- Ernitec 0070-08316-WIPER security camera Bulb IP security camera Indoor & outdoor 2592 x 1944 pixels Wall
Specifications
98 specifications in 19 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| PTZ control | Yes |
| PTZ modes | Preset point |
| PTZ status display | Yes |
| Auto-tracking | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Alarm input/output | Yes |
| Languages support | Multi |
| Number of languages | 10 |
Design
| Specification | Value |
|---|---|
| Form factor | Bulb |
| Mounting type | Wall |
| Product colour | Black, White |
| Housing material | Metal |
| Protection features | Waterproof |
| International Protection (IP) code | IP66 |
| Fog proof | Yes |
Camera
| Specification | Value |
|---|---|
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Minimum illumination | 0 lx |
| Angle of rotation | 360° |
| Lens viewing angle, horizontal | 56.62 - 2.48° |
| Lens viewing angle, vertical | 42.76 - 1.91° |
| Tilt angle range | 0 - 90° |
| Tilt manual speed | 0.1 - 90 °/sec |
| Tilt preset speed | 90 °/sec |
| Pan range | 0 - 360° |
| Pan manual speed | 0.1 - 180 °/sec |
| Pan preset speed | 180 °/sec |
| White balance | Auto, Manual |
| Preset programs quantity | 400 |
| Camera shutter speed | 1/5 - 1/20000 s |
| Number of Privacy masking areas | 40 |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Number of sensors | 1 |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Progressive scan | Yes |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 1 |
| Zoom capability | Yes |
| Optical zoom | 30x |
| Digital zoom | 16x |
| Focal length range | 5.3 - 159 mm |
| Auto focus | Yes |
| Focus | Motorized/Manual |
| Maximum aperture number | 4.3 |
| Minimum aperture number | 1.6 |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 200 m |
| LED type | IR |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 2592 x 1944 pixels |
| Total megapixels | 5 MP |
| Frame rate | 30 fps |
| Noise reduction technology | 3D noise reduction |
| Back Light Compensation (BLC) | Yes |
| Bit rate | 100 kbps - 12 Mbps |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Highlight Compensation (HLC) | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Smart IR | Yes |
Audio
| Specification | Value |
|---|---|
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Audio formats supported | G.711, PCM |
| Signal-to-Noise Ratio (SNR) | 55 dB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Supported network protocols | IPv4, IPv6, TCP / IP, HTTP, HTTPS, UPnP, RTSP / RTP / RTCP, IGMP / Multicast, SMTP, DHCP, NTP, DNS, DDNS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS |
| Number of users | 10 user(s) |
| Streaming method | Unicast |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
| Card reader integrated | Yes |
| Maximum memory card size | 256 GB |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Security
| Specification | Value |
|---|---|
| Alarm input channels | 7 |
| Alarm output channels | 2 |
| Intelligent Video Surveillance (IVS) system features | Crossing line, Human detection, Intrusion, People counting, Vehicle detection |
| Mirror | Yes |
| Video motion detection | Yes |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC, DC, PoE |
| AC input voltage | 24 V |
| Power consumption (typical) | 30 W |
| DC output voltage | 36 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Height | 362.8 mm |
| Diameter | 22.6 cm |
| Weight | 5.5 kg |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Sustainability compliance | Yes |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
Technical details
| Specification | Value |
|---|---|
| Number of video streams | 3 |
