Cam5MP Bullet IP66
Model ECC120ZEAN 655216012325
46 specifications
- ConnectivityWired
- TypeIP security camera
- Weight330 g
- ColourWhite
- Form factorBullet
- Camera pan controlYes
Overview
- Connectivity
- Wired
- Type
- IP security camera
- Weight
- 330 g
- Colour
- White
- Form factor
- Bullet
- Camera pan control
- Yes
- Brand
- EnGenius
- Category
- Security Camera
- Model
- ECC120Z
- Part number
- ECC120Z
- EAN / UPC
- 655216012325
- Also known as
- EnGenius Cam5MP Bullet IP66
Specifications
46 specifications in 14 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
Design
| Specification | Value |
|---|---|
| Form factor | Bullet |
| Mounting type | Ceiling/wall |
| Product colour | White |
| LED indicators | Yes |
| International Protection (IP) code | IP66 |
| Country of origin | Taiwan |
Camera
| Specification | Value |
|---|---|
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Angle of rotation | 180° |
| Lens viewing angle, horizontal | 78° |
| Lens viewing angle, vertical | 56° |
| Lens viewing angle, diagonal | 103° |
| Tilt angle range | 0 - 90° |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Number of sensors | 1 |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 1 |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 2592 x 1944 pixels |
| Total megapixels | 5 MP |
| Video formats supported | H.264, H.265 |
| Video compression formats | H.264, H.265 |
| Supported graphics resolutions | 2592 x 1944 |
| Supported video modes | 1944p |
| Video recording | Yes |
| Frame rate | 20 fps |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Management features
| Specification | Value |
|---|---|
| Cloud-managed | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | PoE |
| Power consumption (max) | 7.5 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 50 °C |
| Operating relative humidity (H-H) | 0 - 98% |
Weight & dimensions
| Specification | Value |
|---|---|
| Height | 200 mm |
| Diameter | 7.6 cm |
| Weight | 330 g |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
