Digicom IPC531-T03 Bullet IP security camera Indoor

1280 x 720 pixels Ceiling/wall

Model IPC531-T03Part no. 8E4583EAN 8030476006048

61 specifications

Memory4 MB
ConnectivityWired & Wireless
TypeIP security camera
ColourSilver
Form factorBullet
Field of view (FOV) angle88°

See all specifications

Overview

Memory: 4 MB
Connectivity: Wired & Wireless
Type: IP security camera
Colour: Silver
Form factor: Bullet
Field of view (FOV) angle: 88°

Brand: Digicom
Category: Security Camera
Model: IPC531-T03
Part number: 8E4583
EAN / UPC: 8030476006048
Also known as: Digicom IPC531-T03 Bullet IP security camera Indoor 1280 x 720 pixels Ceiling/wall

Specifications

61 specifications in 17 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Day/night mode	Yes
Infrared (IR) cut-off filter	Yes
Antenna type	External
Antennas quantity	1

Design

Specification	Value
Form factor	Bullet
Mounting type	Ceiling/wall
Product colour	Silver
International Protection (IP) code	IP66

Camera

Specification	Value
Field of view (FOV) angle	88°

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 4 mm (1 / 4")

Lens system

Specification	Value
Lens diameter	2.8 mm

Night vision

Specification	Value
Night vision	Yes
Night vision distance	15 m
LED type	IR
Number of illumination LEDs	4

Video

Specification	Value
Maximum resolution	1280 x 720 pixels
Video compression formats	H.264
Supported graphics resolutions	640 x 352, 1280 x 720 (HD 720)
Supported video modes	720p
Frame rate	30 fps

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	Yes
Ethernet interface type	Fast Ethernet
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Supported network protocols	IP, TCP, UDP, HTTP, HTTPS, SMTP, FTP, DHCP, DDNS, RTSP, P2P
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)

Storage

Specification	Value
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Internal memory	4 MB

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
Interface	RJ-45

Security

Specification	Value
Password protection type	Supervisor, User
HTTPS encryption	Yes
Motion sensor	Yes
Security algorithms	WEP, WPA, WPA2

Management features

Specification	Value
Web-based management	Yes
Reset button	Yes

Power

Specification	Value
Power consumption (max)	7.5 W
DC output voltage	12
DC output current	1 A
Power over Ethernet (PoE)	No

Operational conditions

Specification	Value
Operating temperature (T-T)	-10 - 50 °C

System requirements

Specification	Value
Windows operating systems supported	Windows 10 Education, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional
Mobile operating systems supported	Android, iOS

Packaging data

Specification	Value
Package width	245 mm
Package depth	115 mm
Package height	185 mm
Package weight	1.2 kg

Packaging content

Specification	Value
Number of cameras	1
Cables included	LAN (RJ-45)
Mounting kit	Yes
AC adapter included	Yes
Quick start guide	Yes
Resource CD	Yes
