Dahua Technology Lite TPC-DF1241-T-S2 Turret IP security camera Indoor & outdoor
Dahua Technology

Lite TPC-DF1241-T-S2 Turret IP security camera Indoor & outdoor

2336 x 1752 pixels Ceiling/wall

Model TPC-DF1241-T-S2Part no. DHI-TPC-DF1241-TB3F4-DW-S2EAN 6939554923739

73 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight850 g
  • ColourWhite
  • Form factorTurret
  • Minimum illumination0.05 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
850 g
Colour
White
Form factor
Turret
Minimum illumination
0.05 lx
Brand
Dahua Technology
Model
TPC-DF1241-T-S2
Part number
DHI-TPC-DF1241-TB3F4-DW-S2
EAN / UPC
6939554923739
Also known as
Dahua Technology Lite TPC-DF1241-T-S2 Turret IP security camera Indoor & outdoor 2336 x 1752 pixels Ceiling/wall

Specifications

73 specifications in 18 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Dynamic range55 dB

Design

Form factorTurret
Mounting typeCeiling/wall
Product colourWhite
International Protection (IP) codeIP67

Camera

Minimum illumination0.05 lx
Lens viewing angle, horizontal71.2°
Lens viewing angle, vertical52°
Camera pixel size12 µm
Response waveband8 - 14 µm
White balanceAuto, Indoor, Manual, Natural, Outdoor, Street lamp
Camera shutter speed1/30000 - 1 s
Adjustment shutter speedAuto/Manual

Image sensor

Sensor typeCMOS
Number of sensors1
Optical sensor size25.4 / 2.7 mm (1 / 2.7")
Sensor type (thermal module)Vanadium Oxide Uncooled Focal Plane Arrays
Effective sensor resolution (thermal module)256 x 192 pixels

Lens system

Zoom capabilityYes
Digital zoom16x
Focal length range4 mm
Maximum aperture number1

Night vision

Night visionYes
Night vision distance30 m
LED typeIR

Video

Maximum resolution2336 x 1752 pixels
Total megapixels4 MP
Video compression formatsH.264B, H.264H, H.264M, H.265, H.265 Pro
Supported graphics resolutions352 x 288, 640 x 480 (VGA), 704 x 576, 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
Frame rate30 fps
Thermal frame rate (NTSC)50 Hz
Thermal frame rate (PAL)60 Hz
Noise reductionYes
Noise reduction technology2D noise reduction, 3D noise reduction
Back Light Compensation (BLC)Yes
Digital Wide Dynamic Range (DWDR)Yes
Highlight Compensation (HLC)Yes
Region of Interest (ROI) encodingYes

Audio

Audio input channels1.0 channels
Audio output channels1.0 channels
Voice codecsAGC

Network

Ethernet LANYes
Supported network protocolsHTTPS; HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP
Number of users10 user(s)

Storage

Built-in HDDNo
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
RS-485 ports1

Security

Alarm input channels1
Alarm output channels1
Human and vehicle targets classificationYes

Management features

Web browserYes

Power

Power source typeDC, PoE
Power consumption (max)13 W
DC output voltage12
DC output current1.2 A

Operational conditions

Operating temperature (T-T)-30 - 50 °C
Storage temperature (T-T)-30 - 70 °C
Operating relative humidity (H-H)0 - 95%

Weight & dimensions

Height122 mm
Diameter12.2 cm
Weight850 g

Packaging data

Package width155 mm
Package depth155 mm
Package height135 mm
Package weight1 kg

Packaging content

Number of cameras1
