Cooper SCA397013 security camera Dome CCTV security camera Indoor
1920 x 1080 pixels Ceiling
Model SCA397013
38 specifications
- ConnectivityWired
- TypeCCTV security camera
- Weight130 g
- ColourBlack, White
- Form factorDome
- Minimum illumination0.04 lx
Overview
- Connectivity
- Wired
- Type
- CCTV security camera
- Weight
- 130 g
- Colour
- Black, White
- Form factor
- Dome
- Minimum illumination
- 0.04 lx
- Brand
- Dahua Technology
- Category
- Security Camera
- Model
- SCA397013
- Part number
- SCA397013
- Also known as
- Dahua Technology Cooper SCA397013 security camera Dome CCTV security camera Indoor 1920 x 1080 pixels Ceiling
Specifications
38 specifications in 14 groups
Performance
| Specification | Value |
|---|---|
| Type | CCTV security camera |
| Placement supported | Indoor |
| Connectivity technology | Wired |
| Day/night mode | Yes |
Design
| Specification | Value |
|---|---|
| Form factor | Dome |
| Mounting type | Ceiling |
| Product colour | Black, White |
| Housing material | Polycarbonate (PC) |
Camera
| Specification | Value |
|---|---|
| Minimum illumination | 0.04 lx |
| Field of view (FOV) angle | 103° |
Image sensor
| Specification | Value |
|---|---|
| Number of sensors | 1 |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 1 |
| Lens diameter | 2.8 mm |
| Maximum aperture number | 1.85 |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 20 m |
| LED type | IR |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Supported video modes | 720p, 1080p |
| Noise reduction | Yes |
| Back Light Compensation (BLC) | Yes |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Highlight Compensation (HLC) | Yes |
| Smart IR | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
| Bluetooth | No |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
Ports & interfaces
| Specification | Value |
|---|---|
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Power consumption (max) | 2.3 W |
| DC output voltage | 12 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Height | 69 mm |
| Diameter | 8.5 cm |
| Weight | 130 g |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
