Dahua Technology 5MP Fixed-focal

Dahua Technology

5MP Fixed-focal

4G Pan & Tilt Network Camera

Model P5AE-PV-4GEAN 6939554928277

84 specifications

ConnectivityWireless
TypeIP security camera
Weight500 g
ColourBlack, White
Form factorTurret
Camera pan controlYes

See all specifications

Overview

Connectivity: Wireless
Type: IP security camera
Weight: 500 g
Colour: Black, White
Form factor: Turret
Camera pan control: Yes

Brand: Dahua Technology
Category: Security Camera
Model: P5AE-PV-4G
Part number: P5AE-PV-4G
EAN / UPC: 6939554928277
Also known as: Dahua Technology 5MP Fixed-focal 4G Pan & Tilt Network Camera

Specifications

84 specifications in 20 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wireless
PTZ control	Yes
Auto-tracking	Yes
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Built-in light	Yes
Plug and Play	Yes

Design

Specification	Value
Form factor	Turret
Mounting type	Ceiling/wall
Product colour	Black, White
LED indicators	Yes
Housing material	Plastic
Protection features	Dustproof, Rain proof, Waterproof, Wind resistant
International Protection (IP) code	IP66
Weatherproof	Yes

Camera

Specification	Value
Camera pan control	Yes
Camera tilt control	Yes
Angle of rotation	180°
Lens viewing angle, horizontal	81.27°
Lens viewing angle, vertical	47.73°
Lens viewing angle, diagonal	94.41°
Tilt angle range	0 - 90°
Pan range	0 - 345°
Camera shutter type	Electronic
Camera shutter speed	1/25 - 1/100000 s

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 2.8 mm (1 / 2.8")

Panoramic camera

Specification	Value
Digital Wide Dynamic Range (DWDR) (panoramic camera)	Yes

Lens system

Specification	Value
Fixed focus	Yes
Maximum aperture number	1.6
Fixed focal length	4 mm

Night vision

Specification	Value
Night vision	Yes
Night vision distance	30 m
LED type	IR/White
Number of illumination LEDs	4

Video

Specification	Value
Maximum resolution	2880 x 1620 pixels
Total megapixels	5 MP
Video compression formats	H.264+, H.264B, H.264H, H.264M, H.265, H.265+, M-JPEG
Video streaming	Yes
Bit rate	H264: 64 - 8192 kbps H265: 25 - 6400 kbps

Audio

Specification	Value
Built-in speaker(s)	Yes
Audio system	2-way
Built-in microphone	Yes
Voice codecs	G.711Mu, G.711a, G.726, PCM

Network

Specification	Value
Ethernet LAN	No
Wi-Fi	No
Bluetooth	No
Mobile network connection	Yes
SIM card slot	Yes
Mobile network generation	4G
4G standard	LTE-FDD
Live view	Yes

Storage

Specification	Value
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB

Security

Specification	Value
Alert notification type	Push notification
Intelligent Video Surveillance (IVS) system features	Human detection, Intrusion, Tripwire, Vehicle detection
Privacy protection	Yes
Video motion detection	Yes

Management features

Specification	Value
Remotely operated	Yes
Reset button	Yes
Management software	DMSS

Power

Specification	Value
Power source type	DC
Power consumption (typical)	3 W
Power consumption (max)	9 W
DC output voltage	12
DC output current	1 A
Surge protection voltage	2 kV

Operational conditions

Specification	Value
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	0 - 95%

System requirements

Specification	Value
Mobile operating systems supported	Android, iOS

Weight & dimensions

Specification	Value
Height	140.5 mm
Diameter	11.1 cm
Weight	500 g

Sustainability

Specification	Value
Compliance certificates	CE

Packaging content

Specification	Value
Number of cameras	1
Mounting brackets included	Yes
Screws included	Yes
AC adapter included	Yes
Quick start guide	Yes

Technical details

Specification	Value
Iris	Yes
