KIT/BP4A-4G-0360B/M0508 security camera IP security camera Outdoor
2560 x 1440 pixels Wall
Model KIT/BP4A-4G-0360B/M0508
56 specifications
- Battery68 Wh
- ConnectivityWireless
- TypeIP security camera
- Weight1.05 kg
- ColourWhite
- Mounting typeWall
Overview
- Battery
- 68 Wh
- Connectivity
- Wireless
- Type
- IP security camera
- Weight
- 1.05 kg
- Colour
- White
- Mounting type
- Wall
- Brand
- Dahua Technology
- Category
- Security Camera
- Model
- KIT/BP4A-4G-0360B/M0508
- Part number
- KIT/BP4A-4G-0360B/M0508
- Also known as
- Dahua Technology KIT/BP4A-4G-0360B/M0508 security camera IP security camera Outdoor 2560 x 1440 pixels Wall
Specifications
56 specifications in 19 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Outdoor |
| Connectivity technology | Wireless |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
Design
| Specification | Value |
|---|---|
| Mounting type | Wall |
| Product colour | White |
| Housing material | Plastic |
| Protection features | Dustproof, Waterproof |
| International Protection (IP) code | IP66 |
Camera
| Specification | Value |
|---|---|
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Angle of rotation | 360° |
| Lens viewing angle, horizontal | 78.4° |
| Lens viewing angle, vertical | 42.4° |
| Lens viewing angle, diagonal | 92.4° |
| Tilt angle range | -60 - 0° |
| Pan range | 0 - 360° |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
Lens system
| Specification | Value |
|---|---|
| Maximum aperture number | 1.6 |
| Fixed focal length | 3.6 mm |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 2560 x 1440 pixels |
| Total megapixels | 4 MP |
| Video compression formats | H.265 |
| Frame rate | 15 fps |
| Video streaming | Yes |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Audio formats supported | G.711 A-law |
| Built-in microphone | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Mobile network connection | Yes |
| Mobile network generation | 4G |
| 4G standard | LTE-FDD |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB port | Yes |
Security
| Specification | Value |
|---|---|
| Video motion detection | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | USB, Solar |
| Battery capacity | 68 Wh |
Battery
| Specification | Value |
|---|---|
| Battery technology | Lithium |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -20 - 60 °C |
System requirements
| Specification | Value |
|---|---|
| Mobile operating systems supported | Android, iOS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 172 mm |
| Height | 360 mm |
| Length | 284 mm |
| Weight | 1.05 kg |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | CE |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
| Manual | Yes |
