Dahua Technology Ultra-Smart IPC-HUM8101P Box IP security camera Indoor

1280 x 960 pixels

Model IPC-HUM8101PPart no. 1.0.01.04.11615

70 specifications

ConnectivityWired
TypeIP security camera
Weight460 g
ColourBlack, White
Form factorBox
Minimum illumination0.001 lx

See all specifications

Overview

Connectivity: Wired
Type: IP security camera
Weight: 460 g
Colour: Black, White
Form factor: Box
Minimum illumination: 0.001 lx

Brand: Dahua Technology
Category: Security Camera
Model: IPC-HUM8101P
Part number: 1.0.01.04.11615
Also known as: Dahua Technology Ultra-Smart IPC-HUM8101P Box IP security camera Indoor 1280 x 960 pixels

Specifications

70 specifications in 18 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Day/night mode	Yes
Alarm input/output	Yes

Design

Specification	Value
Form factor	Box
Product colour	Black, White

Camera

Specification	Value
Minimum illumination	0.001 lx
Field of view (FOV) angle	77°
White balance	Auto, Manual
Camera shutter type	Electronic
Camera shutter speed	1/3 - 1/100000 s
Adjustment shutter speed	Auto/Manual

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 3 mm (1 / 3")
Progressive scan	Yes

Lens system

Specification	Value
Focus	Manual
Maximum aperture number	2.8
Fixed focal length	3.6 mm

Night vision

Specification	Value
Night vision	No

Video

Specification	Value
Maximum resolution	1280 x 960 pixels
Total megapixels	1.3 MP
Video compression formats	H.264, M-JPEG
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1280 x 960
Supported video modes	720p
Frame rate	30 fps
Video streaming	Yes
Noise reduction	Yes
3D NR (Noise Reduction)	Yes
Gain control type	Auto/Manual
Back Light Compensation (BLC)	Yes
Bit rate	H.264: 48K ~ 8192Kbps
Highlight Compensation (HLC)	Yes
Privacy masking	Yes

Audio

Specification	Value
Audio input channels	1.0 channels
Audio output channels	1.0 channels
Audio codecs	G.711a / G.711u/PCM
Signal-to-Noise Ratio (SNR)	50 dB
Audio detection	Yes

Network

Specification	Value
Ethernet LAN	Yes
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
Networking standards	IEEE 802.3af
Supported network protocols	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
Cabling technology	10/100/1000Base-T(X)
Number of users	20 user(s)
Quality of Service (QoS) support	Yes
Client interoperability	ONVIF, PSIA,CGI

Storage

Specification	Value
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
Interface	RJ-45

Security

Specification	Value
Intelligent Video Surveillance (IVS) system features	Abandoned object, Face detection, Intrusion, Missing object, Scene change, Tripwire

Power

Specification	Value
Power source type	PoE
Power consumption (max)	7 W
DC output voltage	12
Power over Ethernet (PoE)	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95%

System requirements

Specification	Value
Mobile operating systems supported	Android, Windows Phone, iOS

Weight & dimensions

Specification	Value
Width	109.7 mm
Depth	82.8 mm
Height	24 mm
Weight	460 g

Packaging content

Specification	Value
Number of cameras	1

Technical details

Specification	Value
Lens mount interface	Board mount
Number of video streams	3
