Dahua Technology WizMind 8MP Smart Dual Light Fixed-focal Bullet Network Camera
Dahua Technology

WizMind 8MP Smart Dual Light Fixed-focal Bullet Network Camera

Model IPC-HFW5859T-ASE-ILEAN 6937552413498

119 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight835 g
  • ColourWhite
  • Form factorBullet
  • Minimum illumination0.0004 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
835 g
Colour
White
Form factor
Bullet
Minimum illumination
0.0004 lx
Brand
Dahua Technology
Model
IPC-HFW5859T-ASE-IL
Part number
IPC-HFW5859T-ASE-IL
EAN / UPC
6937552413498
Also known as
Dahua Technology WizMind 8MP Smart Dual Light Fixed-focal Bullet Network Camera

Specifications

119 specifications in 22 groups

Performance

TypeIP security camera
Placement supportedOutdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Alarm input/outputYes
Built-in lightYes
Dynamic range120 dB
Smart search functionYes

Design

Form factorBullet
Mounting typeCeiling/Wall/Pole
Product colourWhite
Housing materialMetal
Protection featuresVandal proof, Corrosion resistant
International Protection (IP) codeIP67
IK codeIK10
Fog proofYes

Camera

Minimum illumination0.0004 lx
Angle of rotation360°
Lens viewing angle, horizontal88°
Lens viewing angle, vertical49°
Lens viewing angle, diagonal100°
Tilt angle range0 - 90°
Pan range0 - 360°
White balanceAuto, Street lamp, Outdoor, Natural, Manual, Regional custom
Camera shutter typeElectronic, Mechanical
Camera shutter speed1/3 - 1/100000 s
Number of Privacy masking areas8

Image sensor

Sensor typeCMOS
Number of sensors1
Optical sensor size25.4 / 1.8 mm (1 / 1.8")
Progressive scanYes

Lens system

Number of lenses1
Detect distance98 m
Observe distance39.2 m
Recognize distance19.6 m
Fixed focusYes
Identify distance9.8 m
Maximum aperture number1.6
Closest focusing distance2.5 m
Fixed focal length3.6 mm
Lens distortion correction (LDC)Yes

Night vision

Night visionYes
Night vision distance80 m
LED typeIR/White
Number of illumination LEDs4

Video

Maximum resolution3840 x 2160 pixels
Total megapixels8 MP
Video compression formatsH.265, H.264, H.264H, H.264B, M-JPEG, H.265+, H.264+
Supported graphics resolutions3840 x 2160, 3072 x 2048, 3200 x 1800, 3072 x 1728, 2592 x 1944, 2688 x 1520, 2560 x 1440, 2048 x 1536 (QXGA), 2304 x 1296, 1920 x 1080 (HD 1080), 1280 x 960, 1280 x 720 (HD 720), 704 x 576, 704 x 480, 640 x 480 (VGA), 352 x 288, 352 x 240
Supported video modes2160p, 1944p, 1536p, 1520p, 1440p, 1296p, 1080p, 960p, 720p, 576p, 480p, 240p
Frame rate30 fps
Video streamingYes
Image rotation angles270°
Noise reductionYes
Noise reduction technology3D noise reduction
Gain control typeAuto/Manual
Back Light Compensation (BLC)Yes
Bit rate3 kbps–16384 kbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Highlight Compensation (HLC)Yes
Privacy maskingYes
Region of Interest (ROI) encodingYes
Scene self-adaptation (SSA)Yes
Smart IRYes

Audio

Built-in speaker(s)No
Audio system1-way
Audio input channels1.0 channels
Audio output channels1.0 channels
Audio codecsG.711a; G.711Mu; PCM; G.726; G.723
Signal-to-Noise Ratio (SNR)56 dB
Built-in microphoneYes

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Networking standardsIEEE 802.3at
Supported network protocolsIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Auto Registration
Cabling technology10/100Base-T(X)
Number of users20 user(s)
Quality of Service (QoS) supportYes

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size1 TB

Ports & interfaces

Ethernet LAN (RJ-45) ports1

Security

Alarm input channels1
Alarm output channels1
Intelligent Video Surveillance (IVS) system featuresIntrusion, Tripwire, Vehicle detection, Human detection, Pet detection, Face detection, People counting, Heat map
MirrorYes
Motion detection systemSMD 4.0
Network access storage (NAS)Yes
Video motion detectionYes

Management features

Web browserYes
Management softwareDSS; DMSS; DoLynk Care

Power

Power source typeDC, PoE
Power consumption (typical)4.2 W
Power consumption (max)13.3 W
Power consumption (Power over Ethernet (PoE))15.6 W
Power consumption (Power over Ethernet (PoE)) (max)6.3 W
DC output voltage12

Operational conditions

Operating temperature (T-T)-40 - 60 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%

System requirements

Mobile operating systems supportedAndroid, iOS

Weight & dimensions

Width90.7 mm
Height90.7 mm
Length238 mm
Weight835 g

Sustainability

Compliance certificatesCE, Low Voltage Directive (LVD), Electromagnetic Compatibility (EMC)

Packaging data

Package weight1.09 kg

Packaging content

Number of cameras1

Technical details

Audio input1x RCA
IrisYes
Lens mount interfaceM12
Number of video streams4

Other features

Audio output1x RCA
Browser supportedIE: IE 11 and later Chrome: Chrome 102 and later Firefox: Firefox 88 and later
