Dahua Technology IPC-HFW3441DG-AS-4G-EAU-B Cube IP security camera Indoor & outdoor
Dahua Technology

IPC-HFW3441DG-AS-4G-EAU-B Cube IP security camera Indoor & outdoor

2688 x 1520 pixels Wall

Model IPC-HFW3441DG-AS-4G-EAU-BPart no. IPC-HFW3441DG-AS-4G-EAU-B-0280B

95 specifications
  • Memory256 MB
  • ConnectivityWired
  • TypeIP security camera
  • Weight680 g
  • ColourWhite
  • Form factorCube
See all specifications

Overview

Memory
256 MB
Connectivity
Wired
Type
IP security camera
Weight
680 g
Colour
White
Form factor
Cube
Brand
Dahua Technology
Model
IPC-HFW3441DG-AS-4G-EAU-B
Part number
IPC-HFW3441DG-AS-4G-EAU-B-0280B
Also known as
Dahua Technology IPC-HFW3441DG-AS-4G-EAU-B Cube IP security camera Indoor & outdoor 2688 x 1520 pixels Wall

Specifications

95 specifications in 19 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Alarm input/outputYes
Antenna typeExternal
Antennas quantity2
Dynamic range120 dB
CertificationCE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; CE-RED: Radio Equipment Directive 2014/53/EU; FCC: 47 CFR FCC Part 15; Subpart B

Design

Form factorCube
Mounting typeWall
Product colourWhite
Housing materialMetal, Plastic
International Protection (IP) codeIP67

Camera

Minimum illumination0.001 lx
Field of view (FOV) angle102°
Angle of rotation360°
Lens viewing angle, horizontal102°
Lens viewing angle, vertical54°
Lens viewing angle, diagonal121°
Tilt angle range-60 - 0°
Pan range0 - 360°
White balanceAuto, Manual, Natural, Regional custom, Street lamp
Camera shutter typeElectronic
Camera shutter speed1/3 - 1/100000 s
Number of Privacy masking areas4

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 3 mm (1 / 3")
Progressive scanYes

Lens system

Number of lenses1
Detect distance63.6 m
Observe distance25.4 m
Recognize distance12.7 m
Identify distance6.4 m
Maximum aperture number1.6
Fixed focal length2.8 mm

Night vision

Night visionYes

Video

Maximum resolution2688 x 1520 pixels
Total megapixels4 MP
Video formats supportedH.264, H.264B, H.265
Video compression formatsH.264, H.264B, H.264H, H.265
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2688 x 1520
Frame rate30 fps
Video streamingYes
Noise reductionYes
Noise reduction technology3D noise reduction
Gain control typeAuto
Back Light Compensation (BLC)Yes
Bit rateH.264: 32 kbps–8192 kbps H.265: 32 kbps–8192 kbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Highlight Compensation (HLC)Yes
Region of Interest (ROI) encodingYes

Audio

Built-in speaker(s)Yes
Audio input channels1.0 channels
Audio output channels1.0 channels
Audio formats supportedG.711 A-law, G.711 μ-law, G.726, PCM
Signal-to-Noise Ratio (SNR)56 dB
Built-in microphoneYes

Network

Ethernet LANYes
Wi-FiYes
BluetoothNo
Supported network protocolsIPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P
3G standardsWCDMA
4G standardLTE-TDD & LTE-FDD
Number of users20 user(s)

Storage

Built-in HDDYes
eMMC capacity8 GB
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB
ROM capacity128 MB
RAM capacity256 MB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
RS-485 ports1

Security

MirrorYes
Video motion detectionYes

Management features

Web browserYes

Power

Power source typeDC
AC input voltage12 V
Power consumption (typical)4 W
Power consumption (max)7.5 W

Operational conditions

Operating temperature (T-T)-40 - 60 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)0 - 95%

System requirements

Mobile operating systems supportedAndroid, iOS

Weight & dimensions

Width219 mm
Depth132 mm
Height179 mm
Weight680 g

Packaging data

Package width239 mm
Package depth280 mm
Package height146 mm
Package weight1.18 kg

Packaging content

Number of cameras1
