Dahua Technology WizSense IPC-HFW21249T-AS-IL
Dahua Technology

WizSense IPC-HFW21249T-AS-IL

12MP Smart Dual Light Fixed-focal Bullet Network Camera

Model IPC-HFW21249T-AS-ILPart no. IPC-HFW21249T-AS-IL-0280B-BEAN 6939554951367

101 specifications
  • Memory512 MB
  • ConnectivityWired
  • TypeIP security camera
  • Weight720 g
  • ColourBlack
  • Form factorBullet
See all specifications

Overview

Memory
512 MB
Connectivity
Wired
Type
IP security camera
Weight
720 g
Colour
Black
Form factor
Bullet
Brand
Dahua Technology
Model
IPC-HFW21249T-AS-IL
Part numbers
IPC-HFW21249T-AS-IL-0280B-B, IPC-HFW21249T-AS-IL-0280B
EAN / UPC
6939554951367, 6939554913884
Also known as
Dahua Technology WizSense IPC-HFW21249T-AS-IL 12MP Smart Dual Light Fixed-focal Bullet Network Camera

Specifications

101 specifications in 20 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Alarm input/outputYes
Built-in lightYes
CertificationCE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Design

Form factorBullet
Mounting typeCeiling/Wall/Pole
Product colourBlack
Housing materialMetal
International Protection (IP) codeIP67
IK codeIK10

Camera

Minimum illumination0 lx
Angle of rotation360°
Lens viewing angle, horizontal112°
Lens viewing angle, vertical58°
Lens viewing angle, diagonal136°
Tilt angle range0 - 90°
Pan range0 - 360°
White balanceAuto, Natural, Street lamp, Manual, Outdoor, Regional custom
Camera shutter typeElectronic, Mechanical
Camera shutter speed1/3 - 1/100000 s
Number of Privacy masking areas4

Image sensor

Sensor typeCMOS
Optical sensor size25.4 / 2.5 mm (1 / 2.5")
Progressive scanYes

Lens system

Number of lenses1
Detect distance98.9 m
Observe distance39.6 m
Recognize distance19.8 m
Fixed focusYes
Identify distance9.9 m
Maximum aperture number1.6
Closest focusing distance3.5 m
Fixed focal length2.8 mm

Night vision

Night visionYes
Night vision distance30 m
LED typeIR/White
Number of illumination LEDs4

Video

Maximum resolution4480 x 2512 pixels
Total megapixels12 MP
Video compression formatsH.265, H.264, H.264H, H.264B, M-JPEG, H.265+, H.264+
Supported graphics resolutions3840 x 2160, 3072 x 2048, 3072 x 1728, 2880 x 1620, 2688 x 1520, 2304 x 1296, 1280 x 960, 704 x 576, 704 x 480, 352 x 288, 352 x 240
Supported video modes2160p, 1620p, 1520p, 1536p, 1296p, 1080p, 960p, 720p, 480p, 576p, 2880p, 240p
Video streamingYes
Noise reductionYes
Noise reduction technology3D noise reduction
Gain control typeAuto/Manual
Back Light Compensation (BLC)Yes
Bit rateH.264: 32 kbps–8192 kbps; H.265: 12 kbps–8192 kbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Digital Wide Dynamic Range (DWDR)Yes
Highlight Compensation (HLC)Yes
Privacy maskingYes
Region of Interest (ROI) encodingYes

Audio

Audio input channels1.0 channels
Audio output channels1.0 channels
Built-in microphoneYes
Number of microphones1
Voice codecsG.711a, G.711Mu, PCM, G.726

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Networking standardsIEEE 802.3af
Supported network protocolsIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; P2P; Bonjour; Auto Registration
Number of users20 user(s)
Client interoperabilityONVIF (Profile S & Profile G & Profile T); CGI

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB
ROM capacity128 MB
RAM capacity512 MB

Ports & interfaces

Ethernet LAN (RJ-45) ports1

Security

Intelligent Video Surveillance (IVS) system featuresIntrusion, Tripwire
Video motion detectionYes

Power

Power source typeDC, PoE
Power consumption (typical)3.1 W
Power consumption (max)10.1 W
Power consumption (Power over Ethernet (PoE))3.7 W
DC output voltage12

Operational conditions

Operating temperature (T-T)-40 - 60 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%

System requirements

Mobile operating systems supportedAndroid, iOS

Weight & dimensions

Width90.7 mm
Height90.7 mm
Length238.5 mm
Weight720 g

Packaging data

Package weight970 g

Packaging content

Number of cameras1

Technical details

Audio inputRCA
IrisYes
Lens mount interfaceM12

Other features

Audio outputRCA
Browser supportedIE; Chrome; Firefox
Data transfer rate100 Mbit/s
