WizMind IPC-HF7442F-Z-S2 Bullet IP security camera Indoor & outdoor
2688 x 1520 pixels Ceiling/wall
Model IPC-HF7442F-Z-S2Part no. DH-IPC-HF7442F-Z-S2
86 specifications
- ConnectivityWired
- TypeIP security camera
- Weight850 g
- ColourBlack, White
- Form factorBullet
- Camera shutter typeElectronic
Overview
- Connectivity
- Wired
- Type
- IP security camera
- Weight
- 850 g
- Colour
- Black, White
- Form factor
- Bullet
- Camera shutter type
- Electronic
- Brand
- Dahua Technology
- Category
- Security Camera
- Model
- IPC-HF7442F-Z-S2
- Part number
- DH-IPC-HF7442F-Z-S2
- Also known as
- Dahua Technology WizMind IPC-HF7442F-Z-S2 Bullet IP security camera Indoor & outdoor 2688 x 1520 pixels Ceiling/wall
Specifications
86 specifications in 19 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| People counting function | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Dynamic range | 140 dB |
| Plug and Play | Yes |
| Certification | CE-LVD:EN62368-1 CE-EM:Electromagnetic Compatibility Directive 2014/30/EU FCC:47 CFR FCC Part 15, Subpart B UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
Design
| Specification | Value |
|---|---|
| Form factor | Bullet |
| Mounting type | Ceiling/wall |
| Product colour | Black, White |
| Housing material | Metal, Plastic |
| Fog proof | Yes |
Camera
| Specification | Value |
|---|---|
| Camera shutter type | Electronic |
| Camera shutter speed | 1/3 -1/100000 s |
| Adjustment shutter speed | Auto/Manual |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Number of sensors | 1 |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Progressive scan | Yes |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 1 |
Night vision
| Specification | Value |
|---|---|
| Night vision | No |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 2688 x 1520 pixels |
| Total megapixels | 4 MP |
| Video compression formats | H.264, H.264+, H.264H, H.265, H.265+, M-JPEG |
| Supported graphics resolutions | 704 x 576, 1920 x 1080 (HD 1080), 2688 x 1520 |
| Supported video modes | 576p, 1080p, 1520p |
| Frame rate | 60 fps |
| Video intelligence analytic | Yes |
| Video streaming | Yes |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Gain control type | Auto/Manual |
| Back Light Compensation (BLC) | Yes |
| Bit rate | H.264: 32 kbps–10240 kbps H.265: 12 kbps–9984 kbps |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Highlight Compensation (HLC) | Yes |
| Privacy masking | Yes |
| Region of Interest (ROI) encoding | Yes |
| Smart IR | Yes |
Audio
| Specification | Value |
|---|---|
| Audio input channels | 2.0 channels |
| Audio output channels | 1.0 channels |
| Audio formats supported | AAC |
| Signal-to-Noise Ratio (SNR) | 56 dB |
| Built-in microphone | Yes |
| Voice codecs | G.711Mu, G.711a, G.723, G.726, PCM |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Ethernet interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.3at |
| Supported network protocols | IPv4, IPv6, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, SNMP |
| Number of users | 20 user(s) |
| Quality of Service (QoS) support | Yes |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| RS-485 ports | 1 |
Security
| Specification | Value |
|---|---|
| Alarm input channels | 2 |
| Alarm output channels | 2 |
| Active tampering alarm | Yes |
| Mirror | Yes |
| Privacy protection | Yes |
| Video motion detection | Yes |
Management features
| Specification | Value |
|---|---|
| Web-based management | Yes |
| Web browser | Yes |
| Management software | Smart PSS, DSS, DMSS |
Power
| Specification | Value |
|---|---|
| Power source type | AC, DC, PoE |
| AC input voltage | 24 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mobile operating systems supported | Android, iOS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 86.8 mm |
| Depth | 161.6 mm |
| Height | 74 mm |
| Weight | 850 g |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 970 g |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
| Manual | Yes |
