Dahua Technology IPC-HDBW8242E-Z4FR security camera Box IP security camera
Dahua Technology

IPC-HDBW8242E-Z4FR security camera Box IP security camera

1920 x 1080 pixels Ceiling

Model IPC-HDBW8242E-Z4FR

87 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight990 g
  • ColourWhite
  • Form factorBox
  • Minimum illumination0.002 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
990 g
Colour
White
Form factor
Box
Minimum illumination
0.002 lx
Brand
Dahua Technology
Model
IPC-HDBW8242E-Z4FR
Part number
IPC-HDBW8242E-Z4FR
Also known as
Dahua Technology IPC-HDBW8242E-Z4FR security camera Box IP security camera 1920 x 1080 pixels Ceiling

Specifications

87 specifications in 18 groups

Performance

TypeIP security camera
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Alarm input/outputYes
CertificationCE UL FCC

Design

Form factorBox
Mounting typeCeiling
Product colourWhite
Housing materialMetal
International Protection (IP) codeIP67
IK codeIK10
Fog proofYes

Camera

Minimum illumination0.002 lx
Angle of rotation355°
Lens viewing angle, horizontal40°
Lens viewing angle, vertical22°
Tilt angle range0 - 75°
Pan range0 - 355°
White balanceAuto, Manual
Camera shutter typeElectronic
Camera shutter speed1/3~1/100000 s
Adjustment shutter speedAuto/Manual

Image sensor

Sensor typeCMOS
Number of sensors1
Optical sensor size25.4 / 1.8 mm (1 / 1.8")
Progressive scanYes
Number of effective pixels (H x V)1920 x 1080 pixels

Lens system

Number of lenses1
Zoom capabilityYes
Optical zoom4x
Digital zoom16x
Focal length range8 - 32 mm
FocusMotorized
Maximum aperture number1.53
Closest focusing distance3 m

Night vision

Night visionYes
Night vision distance100 m
LED typeIR
Number of illumination LEDs3

Video

Maximum resolution1920 x 1080 pixels
Total megapixels2 MP
Video compression formatsH.264, H.264+, H.265, H.265+, M-JPEG
Supported video modes720p, 1080p
Frame rate60 fps
Video streamingYes
Noise reductionYes
Noise reduction technology3D noise reduction
Gain control typeAuto/Manual
Back Light Compensation (BLC)Yes
Bit rateH.264: 24~ 10240Kbps H.265: 14~ 6144Kbps
Bit rate controlConstant Bit Rate (CBR), Variable Bit Rate (VBR)
Flip & mirrorYes
Highlight Compensation (HLC)Yes
Privacy maskingYes
Region of Interest (ROI) encodingYes
Smart IRYes

Audio

Audio input channels1.0 channels
Audio output channels1.0 channels
Audio formats supportedAAC, G.711, G.726
Signal-to-Noise Ratio (SNR)50 dB

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Supported network protocolsHTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP; FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP; NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP;S NMP;TLS
Number of users20 user(s)
Streaming methodMulticast, Unicast

Storage

ROM capacity4096 MB

Ports & interfaces

RS-485 ports1

Security

Intelligent Video Surveillance (IVS) system featuresAbandoned object, Intrusion, Missing object, People counting, Tripwire

Management features

Web-based managementYes
Web browserYes
Management softwareSmart PSS, DSS, DMSS

Power

Power source typeAC, DC, PoE
AC input voltage24 V
Power consumption (typical)6.6 W
Power consumption (max)15.84 W
Power consumption (Power over Ethernet (PoE))6.1 W
DC output voltage12

Operational conditions

Operating temperature (T-T)-30 - 60 °C
Storage temperature (T-T)-30 - 60 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%

System requirements

Mobile operating systems supportedAndroid, iOS

Weight & dimensions

Height117.9 mm
Diameter15.9 cm
Weight990 g

Packaging content

Number of cameras1
