Dahua Technology IPC-HDBW1320E Dome IP security camera Indoor & outdoor

2304 x 1536 pixels Ceiling

Model IPC-HDBW1320EPart no. DH-IPC-HDBW1320EN-0360B

72 specifications

Memory256 MB
ConnectivityWired
TypeIP security camera
Weight340 g
ColourBlack, White
Form factorDome

See all specifications

Overview

Memory: 256 MB
Connectivity: Wired
Type: IP security camera
Weight: 340 g
Colour: Black, White
Form factor: Dome

Brand: Dahua Technology
Category: Security Camera
Model: IPC-HDBW1320E
Part number: DH-IPC-HDBW1320EN-0360B
Also known as: Dahua Technology IPC-HDBW1320E Dome IP security camera Indoor & outdoor 2304 x 1536 pixels Ceiling

Specifications

72 specifications in 19 groups

Performance

Specification	Value
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
PTZ control	Yes
Day/night mode	Yes
Certification	CE, UL, FCC

Design

Specification	Value
Form factor	Dome
Mounting type	Ceiling
Product colour	Black, White
Housing material	Metal
Protection features	Dust resistant, Splash proof, Water resistant
International Protection (IP) code	IP67

Camera

Specification	Value
Minimum illumination	0.1 lx
Angle of rotation	355°
Lens viewing angle, horizontal	98°
Lens viewing angle, vertical	51°
Tilt angle range	0 - 65°
Pan range	0 - 355°
White balance	Auto, Lamp, Manual, Outdoor

Image sensor

Specification	Value
Sensor type	CMOS
Optical sensor size	25.4 / 3 mm (1 / 3")
Progressive scan	Yes

Lens system

Specification	Value
Zoom capability	Yes
Digital zoom	16x
Lens diameter	3.6 mm
Maximum aperture number	2
Fixed focal length	2.8 mm

Night vision

Specification	Value
Night vision	Yes
Night vision distance	30 m
LED type	IR
Number of illumination LEDs	24

Video

Specification	Value
Maximum resolution	2304 x 1536 pixels
Total megapixels	3 MP
Video formats supported	H.264
Video compression formats	H.264
Supported graphics resolutions	2304 x 1296, 352 x 240, 352 x 288, 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA)
Supported video modes	720p, 1080p
Frame rate	30 fps
Analog signal format system	NTSC
Noise reduction	Yes
Automatic gain control	Yes
Flip & mirror	Yes
Privacy masking	Yes

Audio

Specification	Value
Signal-to-Noise Ratio (SNR)	50 dB

Network

Specification	Value
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;DHC P;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP;Bonjour ;802.1x;Multicast;ICMP;IGMP
Cabling technology	10/100Base-T(X)
Number of users	20 user(s)

Storage

Specification	Value
Built-in HDD	No
Flash memory	16 MB
Internal memory	256 MB

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
Interface	RJ-45

Security

Specification	Value
Motion sensor	Yes
Video motion detection	Yes

Power

Specification	Value
Power source type	PoE
Power consumption (typical)	5 W
Power consumption (Power over Ethernet (PoE))	5 W
Power over Ethernet (PoE)	Yes

Operational conditions

Specification	Value
Operating temperature (T-T)	-30 - 60 °C

System requirements

Specification	Value
Mac compatibility	Yes
Windows operating systems supported	Yes
Mobile operating systems supported	Android, iOS

Weight & dimensions

Specification	Value
Height	81 mm
Diameter	11 cm
Weight	340 g

Packaging data

Specification	Value
Package weight	470 g

Packaging content

Specification	Value
Number of cameras	1
Manual	Yes
Quick start guide	Yes

Technical details

Specification	Value
Lens type	Standard
