Cooper HAC-B2A21 Bullet IP security camera Indoor & outdoor
1920 x 1080 pixels Ceiling/wall
Model HAC-B2A21Part no. DH-HAC-B2A21-0360BEAN 6939554970245
64 specifications
- ConnectivityWired
- TypeIP security camera
- Weight250 g
- ColourWhite
- Form factorBullet
- Minimum illumination0.004 lx
Overview
- Connectivity
- Wired
- Type
- IP security camera
- Weight
- 250 g
- Colour
- White
- Form factor
- Bullet
- Minimum illumination
- 0.004 lx
- Brand
- Dahua Technology
- Category
- Security Camera
- Model
- HAC-B2A21
- Part numbers
- DH-HAC-B2A21-0360B, DH-HAC-B2A21-0280B, DH-HAC-B2A21-0600B
- EAN / UPC
- 6939554970245
- Also known as
- Dahua Technology Cooper HAC-B2A21 Bullet IP security camera Indoor & outdoor 1920 x 1080 pixels Ceiling/wall
Specifications
64 specifications in 16 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Languages support | Multi |
| Certification | CE (EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014, EN62368-1:2014+A11:2017) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
Design
| Specification | Value |
|---|---|
| Form factor | Bullet |
| Mounting type | Ceiling/wall |
| Product colour | White |
| Housing material | Metal |
| International Protection (IP) code | IP67 |
Camera
| Specification | Value |
|---|---|
| Minimum illumination | 0.004 lx |
| Field of view (FOV) angle | 82° |
| Angle of rotation | 360° |
| Tilt angle range | 0 - 90° |
| Pan range | 0 - 360° |
| White balance | Auto |
| Camera shutter speed | 1/100000 s |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
| Number of sensors | 1 |
| Progressive scan | Yes |
| Number of effective pixels (H x V) | 1920 x 1080 pixels |
Lens system
| Specification | Value |
|---|---|
| Number of lenses | 1 |
| Detect distance | 60.9 m |
| Observe distance | 24.3 m |
| Recognize distance | 12.2 m |
| Lens diameter | 3.6 mm |
| Identify distance | 6.1 m |
| Maximum aperture number | 2 |
| Normal focusing range | 1 m |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 1920 x 1080 pixels |
| Total megapixels | 2 MP |
| Supported video modes | 720p, 1080p |
| Frame rate | 30 fps |
| Analog signal format system | NTSC, PAL |
| Noise reduction | Yes |
| Noise reduction technology | 2D noise reduction |
| Back Light Compensation (BLC) | Yes |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Highlight Compensation (HLC) | Yes |
| Smart IR | Yes |
Audio
| Specification | Value |
|---|---|
| Signal-to-Noise Ratio (SNR) | 65 dB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Wi-Fi | No |
| Bluetooth | No |
Storage
| Specification | Value |
|---|---|
| Built-in HDD | No |
Ports & interfaces
| Specification | Value |
|---|---|
| BNC output ports | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Power consumption (max) | 2.7 W |
| DC output voltage | 12 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 157.6 mm |
| Depth | 70.1 mm |
| Height | 70.1 mm |
| Weight | 250 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 182 mm |
| Package depth | 90 mm |
| Package height | 77 mm |
| Package weight | 300 g |
Packaging content
| Specification | Value |
|---|---|
| Number of cameras | 1 |
