Dahua Technology WizSense DH-SD5A225XA1-HNR security camera Bullet IP security camera Indoor & outdoor
Dahua Technology

WizSense DH-SD5A225XA1-HNR security camera Bullet IP security camera Indoor & outdoor

1920 x 1080 pixels Ceiling

Model DH-SD5A225XA1-HNR

97 specifications
  • Memory1024 MB
  • ConnectivityWired
  • TypeIP security camera
  • Weight4.7 kg
  • ColourBlack, White
  • Form factorBullet
See all specifications

Overview

Memory
1024 MB
Connectivity
Wired
Type
IP security camera
Weight
4.7 kg
Colour
Black, White
Form factor
Bullet
Brand
Dahua Technology
Model
DH-SD5A225XA1-HNR
Part number
DH-SD5A225XA1-HNR
Also known as
Dahua Technology WizSense DH-SD5A225XA1-HNR security camera Bullet IP security camera Indoor & outdoor 1920 x 1080 pixels Ceiling

Specifications

97 specifications in 21 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
PTZ controlYes
PTZ modes5 Pattern, 8 Tour
PTZ protocolsDH-SD, Pelco-P/D
Auto-trackingYes
Wide Dynamic Range (WDR)Yes
CertificationCE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB,ANSI C63.4- 2014 UL:UL60950-1+CAN/CSA C22.2,No.60950-1

Design

Form factorBullet
Mounting typeCeiling
Product colourBlack, White
Housing materialMetal
International Protection (IP) codeIP67
IK codeIK10

Camera

Minimum illumination0 lx
Lens viewing angle, horizontal58.7°
Lens viewing angle, vertical33.2°
Lens viewing angle, diagonal67.3°
Tilt angle range-15 - 90°
Tilt preset speed300 °/sec
Tilt speed200 °/sec
Pan range0 - 360°
Pan preset speed400 °/sec
Pan speed300 °/sec
White balanceAuto, Indoor, Manual, Natural, Outdoor, Sodium lamp, Street lamp
Preset programs quantity300
Camera shutter speed1/3 - 1/30000 s

Image sensor

Sensor typeCMOS
Number of sensors1
Optical sensor size25.4 / 2.8 mm (1 / 2.8")
Progressive scanYes

Panoramic camera

Maximum aperture number (panoramic camera)3.5

Lens system

Number of lenses1
Zoom capabilityYes
Optical zoom25x
Digital zoom16x
Focal length range5.4 - 135 mm
Closest focusing distance1.5 m
Detect distance (wide)1655 m
Identify distance (wide)166 m
Observe distance (wide)657 m
Recognize distance (wide)331 m

Night vision

Night visionYes
Night vision distance150 m
LED typeIR
Number of illumination LEDs4

Video

Maximum resolution1920 x 1080 pixels
Total megapixels2 MP
Video compression formatsH.264, H.264+, H.265, H.265+
Supported graphics resolutions352 x 240, 352 x 288, 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
Noise reductionYes
Noise reduction technology2D noise reduction, 3D noise reduction
Image stabilizerYes
Gain control typeAuto/Manual
Back Light Compensation (BLC)Yes
Bit rate3 Kbps - 20480 Kbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR), Variable Bit Rate (VBR)
Flip & mirrorYes
Highlight Compensation (HLC)Yes
Privacy maskingYes
Region of Interest (ROI) encodingYes

Audio

Audio input channels1.0 channels
Audio output channels1.0 channels
Audio formats supportedAAC, G.711 A-law, G.722.1, G.726

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3(MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP; RTMP
Number of users20 user(s)
Streaming methodMulticast, Unicast
Client interoperabilityONVIF Profile S&G&T; CGI

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB
Internal memory1024 MB
ROM capacity4096 MB

Ports & interfaces

Ethernet LAN (RJ-45) ports1

Security

Alarm input channels2
Alarm output channels1
Video motion detectionYes

Management features

Web-based managementYes
Web browserYes
Management softwareSmart Player, Smart PSS, DSS, Easy4ip

Power

Power source typeDC, PoE
Power consumption (typical)8 W

Operational conditions

Operating temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)0 - 95%

System requirements

Mobile operating systems supportedAndroid, iOS

Weight & dimensions

Diameter19 cm
Length352 mm
Weight4.7 kg

Packaging data

Package weight8 kg

Packaging content

Number of cameras1

Technical details

IrisYes
