Dahua Technology WizSense DH-IPC-HDW3849H-AS-PV-ANZ security camera Turret IP security camera Indoor & outdoor
Dahua Technology

WizSense DH-IPC-HDW3849H-AS-PV-ANZ security camera Turret IP security camera Indoor & outdoor

3840 x 2160 pixels Ceiling/wall

Model DH-IPC-HDW3849H-AS-PV-ANZ

83 specifications
  • Memory512 MB
  • ConnectivityWired
  • TypeIP security camera
  • Weight745 g
  • ColourWhite
  • Form factorTurret
See all specifications

Overview

Memory
512 MB
Connectivity
Wired
Type
IP security camera
Weight
745 g
Colour
White
Form factor
Turret
Brand
Dahua Technology
Model
DH-IPC-HDW3849H-AS-PV-ANZ
Part number
DH-IPC-HDW3849H-AS-PV-ANZ
Also known as
Dahua Technology WizSense DH-IPC-HDW3849H-AS-PV-ANZ security camera Turret IP security camera Indoor & outdoor 3840 x 2160 pixels Ceiling/wall

Specifications

83 specifications in 18 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Alarm input/outputYes

Design

Form factorTurret
Mounting typeCeiling/wall
Product colourWhite
Housing materialMetal
International Protection (IP) codeIP67

Camera

Minimum illumination0.0004 lx
Angle of rotation360°
Tilt angle range0 - 78°
Pan range0 - 360°
White balanceAuto, Manual, Natural, Outdoor, Regional custom, Street lamp
Camera shutter typeElectronic
Camera shutter speed1/100000 s
Number of Privacy masking areas8

Image sensor

Sensor typeCMOS
Number of sensors1
Optical sensor size25.4 / 2.8 mm (1 / 2.8")
Progressive scanYes

Lens system

Number of lenses1
Fixed focusYes

Night vision

Night visionYes
Night vision distance30 m
LED typeIR/White
Number of illumination LEDs2

Video

Maximum resolution3840 x 2160 pixels
Total megapixels8 MP
Video compression formatsH.264, H.264+, H.264B, H.264H, H.265, H.265+, M-JPEG
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1536 x 2048, 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2592 x 1944, 2688 x 1520, 3072 x 1728, 3072 x 2048, 3840 x 2160
Frame rate30 fps
Video streamingYes
Noise reductionYes
Noise reduction technology3D noise reduction
Gain control typeAuto/Manual
Back Light Compensation (BLC)Yes
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Highlight Compensation (HLC)Yes
Region of Interest (ROI) encodingYes
Smart IRYes

Audio

Audio input channels1.0 channels
Audio output channels1.0 channels
Audio formats supportedG.711 A-law, G.711 μ-law, G.723, G.726, PCM
Signal-to-Noise Ratio (SNR)56 dB
Built-in microphoneYes

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Number of users20 user(s)

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size256 GB
ROM capacity128 MB
RAM capacity512 MB

Security

Alarm input channels1
Alarm output channels1
Digital watermarkYes
Intelligent Video Surveillance (IVS) system featuresIntrusion, Tripwire
MirrorYes
Security algorithmsHTTPS
Video motion detectionYes

Management features

Web-based managementYes
Management softwareSmart PSS; DSS; DMSS

Power

Power source typeDC, PoE
Power consumption (typical)5.2 W
Power consumption (max)9.2 W
Power consumption (Power over Ethernet (PoE))5.5 W
DC output voltage12

Operational conditions

Operating temperature (T-T)-40 - 60 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)0 - 95%

System requirements

Mobile operating systems supportedAndroid, iOS

Weight & dimensions

Height110.9 mm
Diameter12.2 cm
Weight745 g

Packaging data

Package weight915 g

Packaging content

Number of cameras1
