Dahua Technology DH-IPC-HDBW4231F-E2-M security camera Dome IP security camera Indoor & outdoor
Dahua Technology

DH-IPC-HDBW4231F-E2-M security camera Dome IP security camera Indoor & outdoor

1920 x 1080 pixels Ceiling

Model DH-IPC-HDBW4231F-E2-M

97 specifications
  • Memory512 MB
  • ConnectivityWired
  • TypeIP security camera
  • Weight505 g
  • ColourWhite
  • Form factorDome
See all specifications

Overview

Memory
512 MB
Connectivity
Wired
Type
IP security camera
Weight
505 g
Colour
White
Form factor
Dome
Brand
Dahua Technology
Model
DH-IPC-HDBW4231F-E2-M
Part number
DH-IPC-HDBW4231F-E2-M
Also known as
Dahua Technology DH-IPC-HDBW4231F-E2-M security camera Dome IP security camera Indoor & outdoor 1920 x 1080 pixels Ceiling

Specifications

97 specifications in 20 groups

Performance

TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Dynamic range120 dB
CertificationCE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B E-mark(ECE-Regulation No.10) EN50155(Environment)

Design

Form factorDome
Mounting typeCeiling
Product colourWhite
Housing materialMetal
Protection featuresVandal proof
International Protection (IP) codeIP67
IK codeIK10

Camera

Minimum illumination0 lx
Angle of rotation360°
Lens viewing angle, horizontal110°
Lens viewing angle, vertical60°
Tilt angle range0 - 65°
Pan range90 - 90°
White balanceAuto, Manual, Natural, Outdoor, Street lamp
Camera shutter speed1/3(4) - 1/100000 s
Adjustment shutter speedAuto/Manual
Number of Privacy masking areas4

Image sensor

Sensor typeCMOS
Number of sensors2
Optical sensor size25.4 / 2.8 mm (1 / 2.8")
Progressive scanYes
Number of effective pixels (H x V)1920 x 1080 pixels

Lens system

Digital zoom16x
Detect distance41 m
Observe distance16 m
Recognize distance8 m
Fixed focusYes
Identify distance4 m
Maximum aperture number2
Fixed focal length2.8 mm

Night vision

Night visionYes
Night vision distance20 m
LED typeIR
Number of illumination LEDs10

Video

Maximum resolution1920 x 1080 pixels
Total megapixels2 MP
Video compression formatsH.264H, H.265
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
Supported video modes720p, 1080p
Frame rate30 fps
Video streamingYes
Noise reductionYes
Noise reduction technology3D noise reduction
Gain control typeAuto/Manual
Back Light Compensation (BLC)Yes
Bit rateH.264: 32~10240Kbps H.265: 12~7168Kbps
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Flip & mirrorYes
Highlight Compensation (HLC)Yes
Privacy maskingYes
Region of Interest (ROI) encodingYes
Smart IRYes

Audio

Audio formats supportedAWB
Signal-to-Noise Ratio (SNR)50 dB
Built-in microphoneYes
Voice codecsAAC, AGC, G.711Mu, G.711a, G.726
Bit rate range7168 - 10240 Kbit/s

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Networking standardsIEEE 802.3af
Supported network protocolsHTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP; FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP; NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP;S NMP;TLS
Number of users20 user(s)
Streaming methodMulticast, Unicast
Client interoperabilityONVIF Profile S&G, API

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Internal memory512 MB
ROM capacity256 MB

Security

Active tampering alarmYes
Intelligent Video Surveillance (IVS) system featuresAbandoned object, Face detection, Intrusion, Missing object, Tripwire
Network access storage (NAS)Yes
Video motion detectionYes

Management features

Web-based managementYes
Management softwareSmart PSS, DSS, DMSS

Power

Power source typeDC, PoE
Power consumption (typical)6.02 W
Power consumption (Power over Ethernet (PoE))6.02 W
DC output voltage12

Operational conditions

Operating temperature (T-T)-30 - 60 °C
Storage temperature (T-T)30 - 60 °C

System requirements

Mobile operating systems supportedAndroid, iOS

Weight & dimensions

Height65.4 mm
Diameter12.2 cm
Weight505 g

Packaging data

Package weight530 g

Packaging content

Number of cameras1

Other features

Browser supportedIE, Chrome, Firefox, Safari

Technical details

Number of video streams2
