PIR ARD1731-W2 IP security camera Indoor
1600 x 1200 pixels Wall
Model ARD1731-W2Part no. DHI-ARD1731-W2
43 specifications
- ConnectivityWireless
- TypeIP security camera
- Weight202 g
- ColourWhite
- Mounting typeWall
- Sensor typeCMOS
Overview
- Connectivity
- Wireless
- Type
- IP security camera
- Weight
- 202 g
- Colour
- White
- Mounting type
- Wall
- Sensor type
- CMOS
- Brand
- Dahua Technology
- Category
- Security Camera
- Model
- ARD1731-W2
- Part number
- DHI-ARD1731-W2
- Also known as
- Dahua Technology PIR ARD1731-W2 IP security camera Indoor 1600 x 1200 pixels Wall
Specifications
43 specifications in 15 groups
Performance
| Specification | Value |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor |
| Connectivity technology | Wireless |
| Maximum operating distance | 1200 m |
| Day/night mode | Yes |
| Operating frequency | 433.1 - 434.6 MHz |
Design
| Specification | Value |
|---|---|
| Mounting type | Wall |
| Product colour | White |
| LED indicators | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
Image sensor
| Specification | Value |
|---|---|
| Sensor type | CMOS |
Lens system
| Specification | Value |
|---|---|
| Detect distance | 12 m |
Night vision
| Specification | Value |
|---|---|
| Night vision | Yes |
| Night vision distance | 12 m |
| LED type | IR |
Video
| Specification | Value |
|---|---|
| Maximum resolution | 1600 x 1200 pixels |
| Total megapixels | 2 MP |
| Supported graphics resolutions | 320 x 240, 640 x 480 (VGA), 1280 x 960, 1600 x 1200 (UXGA) |
Audio
| Specification | Value |
|---|---|
| Audio system | 2-way |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Bluetooth | No |
| Frequency band | 2.4 GHz |
Security
| Specification | Value |
|---|---|
| Temperature sensor | Yes |
| Active tampering alarm | Yes |
| Alert notification type | Snapshot alert message |
| Intelligent Video Surveillance (IVS) system features | Intrusion |
| Security algorithms | 128-bit AES |
Management features
| Specification | Value |
|---|---|
| Firmware upgradeable | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | Battery |
| Battery type | CR123A |
| Number of batteries supported | 3 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 71 mm |
| Depth | 53.2 mm |
| Height | 127.6 mm |
| Weight | 202 g |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | CE |
| Sustainability compliance | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 170 mm |
| Package depth | 65 mm |
| Package height | 121 mm |
| Package weight | 333 g |
