D-Link Vigilance IP security camera Indoor
D-Link

Vigilance IP security camera Indoor

2560 x 1920 pixels Ceiling

Model VigilancePart no. DCS-4612EKEAN 790069461286

95 specifications
  • ConnectivityWired
  • TypeIP security camera
  • Weight190 g
  • ColourBlack, White
  • Mounting typeCeiling
  • Minimum illumination0.01 lx
See all specifications

Overview

Connectivity
Wired
Type
IP security camera
Weight
190 g
Colour
Black, White
Mounting type
Ceiling
Minimum illumination
0.01 lx
Brand
D-Link
Model
Vigilance
Part numbers
DCS-4612EK, DCS-4625, DCS-4614EK, DCS-4712E, DCS-4714E
EAN / UPC
790069461286, 790069448836, 790069456565, 790069457005 +8 more
Also known as
D-Link Vigilance IP security camera Indoor 2560 x 1920 pixels Ceiling

Specifications

95 specifications in 20 groups

Performance

TypeIP security camera
Placement supportedIndoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Infrared (IR) cut-off filterYes
CertificationCE, CE LVD, FCC, RCM

Design

Mounting typeCeiling
Product colourBlack, White

Camera

Minimum illumination0.01 lx
Lens viewing angle, horizontal180°
Lens viewing angle, vertical180°
Lens viewing angle, diagonal180°
White balanceAuto
Camera shutter typeElectronic
Camera shutter speed1/12 ~ 1/27000 s
Adjustment shutter speedAuto

Image sensor

Sensor typeCMOS
Number of sensors1
Optical sensor size25.4 / 2.5 mm (1 / 2.5")
Progressive scanYes

Lens system

Number of lenses1
Detect distance0.5 m
Maximum aperture number2
Fixed focal length1.37 mm

Night vision

Night visionYes
Night vision distance5 m
LED typeIR

Video

Maximum resolution2560 x 1920 pixels
Total megapixels5 MP
Video compression formatsH.264, H.265, M-JPEG
Supported graphics resolutions640 x 360, 640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2560 x 1440, 2560 x 1920
Supported video modes360p, 480p, 720p, 960p, 1080p, 1440p
Frame rate30 fps
Gain control typeAuto
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
Text caption overlayYes
Time stamp overlayYes

Audio

Audio formats supportedLC-AAC
Audio codecsG.711

Network

Ethernet LANYes
Wi-FiNo
BluetoothNo
Ethernet interface typeFast Ethernet
Networking standardsIEEE 802.1x, IEEE 802.3af
Supported network protocolsIPv6, IPv4, ARP, TCP/IP, UDP, ICMP, DHCP client, NTP client (D-Link), DNS client, FTP client, SMTP client, Bonjour, 802.1x, HTTP/HTTPS, PPPoE, UPnP port forwarding, RTP/RTSP/RTCP, CoS, QoS/DSCP, SNMP v1/v2/v3, ONVIF
Quality of Service (QoS) supportYes

Storage

Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size256 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports1
Headphone outputs1

Security

Password protectionYes
Active tampering alarmYes
Alert notification typeE-mail, Snapshot alert message
IP address filteringYes
Security algorithms802.1x RADIUS, HTTPS, SNMP, SNMPv3
Video motion detectionYes

Management features

Web-based managementYes
Web browserYes

Power

Power source typeAC, DC, PoE
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (Power over Ethernet (PoE))8 W
DC output voltage12
DC output current1.5 A

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)5 - 95%

System requirements

Windows operating systems supportedWindows 10, Windows 7, Windows 8

Weight & dimensions

Height29.6 mm
Diameter10.1 cm
Weight190 g

Packaging data

Package width137 mm
Package depth208 mm
Package height95 mm
Package weight690 g

Packaging content

Number of cameras1

Logistics data

Master (outer) cases per pallet (air)40 pc(s)
Master (outer) cases per pallet (sea)56 pc(s)
Pallet gross length110 cm
Pallet gross weight (air)320 kg
Pallet gross weight (sea)440 kg
Pallet gross width120 cm
Pallet height (air)138.5 cm
Pallet height (sea)188.5 cm
Products per pallet (air)400 pc(s)
Products per pallet (sea)560 pc(s)
Shipping (inner) case gross weight7.5 kg
Shipping (inner) case height25 cm
Shipping (inner) case length50.2 cm
Shipping (inner) case net weight6.9 kg
Shipping (inner) case width29.7 cm
Products per shipping (inner) case10 pc(s)
